Altronix NETWAY4EB 4 Port PoE+ Switch Board

SKU: NETWAY4EB

Model #: NETWAY4EB

  • Altronix NETWAY4EB 4 Port PoE+ Switch Board NETWAY4EB by Altronix Altronix NETWAY4EB 4 Port PoE+ Switch Board NETWAY4EB by Altronix

SKU: NETWAY4EB

Model #: NETWAY4EB

Availability: Usually ships in 3 to 5 business day

$290.82

Availability: In stock

Low Price Guarantee

  • Express Checkout:
Free Ground Shipping Free Ground Shipping
Free Lifetime Tech Support Free Lifetime Tech Support
Availability: Usually ships in 3 to 5 business day

Availability: Usually ships in 3 to 5 business day

  • Express Checkout:

Product Details

The NETWAY4EB from Altronix is a PoE+ switch provides a 1Gb SFP port and four (4) PoE+ (30W) ports or up to two (2) Hi-PoE (60W) ports. Cameras/edge devices may be located up to 100m from the unit. Embedded LINQ Technology allows you to monitor, control, and report power and diagnostics from anywhere.

Features

Input

  • 48-55V UL Listed ITE power supply (up to 120W)

Power Output

  • Four (4) ports PoE+ (30W) or up to two (2) Hi-PoE (60W) ports
  • IEEE 802.3at (30W) and IEEE 802.3af (15W) compliant
  • 120W total power
  • Integral surge protection

Fiber Port

  • One (1) Gigabit SFP port
  • Use with SFP module 1000Base-X (1Gb), compliant to Class 1 laser product (not included)

Ethernet

  • Connectivity: RJ45, auto-crossover
  • Wire type: 4-pair Cat-5 or better structured cable
  • Distance: up to 100m
  • Speed: 10/100Mbps, half/full duplex, auto negotiation

Battery Backup

  • Built-in charger for sealed lead acid or gel type batteries
  • Automatic switch over to stand-by battery when AC fails

Indicators (LED)

  • Individual PoE On LEDs for each port
  • Individual IP Link status, 10/100Base-T/active LEDs for each port
  • ALOS LED indicates fiber connection for SFP port
  • Heartbeat LED indicates proper operation of the unit

LINQ Technology

  • Remote network management allows for camera/device reset and monitoring
  • Provides local and/or remote access to critical information via LAN/WAN
  • Email and Windows Dashboard Alert notifications report real-time diagnostics
  • Event log tracks history

Product Specs

SKU  NETWAY4EB
Manufacturer  Altronix
# of Ports  4 PORT
Data Rate  10/100 Mbps
PoE  Yes
Features  Hardened
