Digital Watchdog DWC-C223W 1080p Analog HD-AHD/TVI/CVI Indoor Box Camera, No Lens
SKU
DWC-C223W
Model No
DWC-C223W
was $173.00 Special Price $161.21
Product Highlights
- Universal HD over Coax Technology with HD-Analog, HD-TVI, HD-CVI and all Analog to 960H Signal Support
- STAR-LIGHT Super Low Light Technology
- 2.1MP 1/3″ Image Sensor at Real-time 30fps
- Compatible with C/CS Mount Lens
- True Wide Dynamic Range (WDR)
Speak to an expert
The Digital Watchdog DWC-C223W 1080p Analog HD-AHD/TVI/CVI Indoor Box Camera is equipped with STAR-LIGHT 2.1MP technology, ensuring exceptional clarity and performance in diverse lighting conditions. Ideal for various surveillance needs, this camera offers compatibility with multiple video signal formats while capitalizing on existing coax infrastructure for seamless integration and cost-effectiveness.
Digital Watchdog DWC-C223W Camera Features
- Universal HD over Coax Technology: Supports HD-Analog, HD-TVI, HD-CVI, and all Analog to 960H, providing flexibility and compatibility with existing setups.
- STAR-LIGHT Super Low Light Technology: Enhances image quality in low-light situations for 24/7 surveillance capabilities.
- 2.1MP 1/3” Image Sensor: Delivers real-time 30fps for clear and fluid video playback.
- Compatible with C/CS Mount Lens: Allows for customization with various lens options to suit specific applications.
- True Wide Dynamic Range (WDR): Optimizes the camera's performance in challenging lighting conditions, ensuring detailed images.
- OSD Control Via Coaxial (UTC): Simplifies the setup and configuration through user-friendly on-screen controls.
- Smart DNR 3D Digital Noise Reduction: Provides cleaner video by reducing noise without losing important details.
- True Day/Night Mechanical IR Cut Filter: Ensures accurate color fidelity during the day and enhanced infrared performance at night.
- De-Fog Extreme Weather Image Compensation: Adjusts image processing for clear visuals in foggy or adverse weather.
- Highlight Masking Exposure (HME): Protects details in bright areas while retaining shadow detail.
- Auto Sensing 24VAC/12VDC with Line Lock: Supports flexible power options for easy installation.
- Easy Icon Driven OSD Menu: Features a built-in joystick for straightforward navigation and setup.
- Programmable Privacy Zones: Allows users to block out sensitive areas from recorded footage.
- Auto Gain Control (AGC): Enhances video in varying lighting for consistent quality.
- Backlight Compensation (BLC): Helps in capturing clearer images when the subject is backlit.
- Dynamic Range Compressor (DRC): Reveals low light detail for improved surveillance quality.
- Auto White Balance (AWB): Automatically adjusts color temperature for true color representation.
Digital Watchdog DWC-C223W Detailed Specifications
| Model | DWC-C223W |
| Resolution | 2.1MP |
| Frame Rate | 30fps |
| Signal Support | HD-Analog, HD-TVI, HD-CVI, Analog to 960H |
| Sensor Size | 1/3” |
| Power Supply | 24VAC/12VDC |
| Technology | STAR-LIGHT Super Low Light |
| WDR | True Wide Dynamic Range |
| OSD Menu | Icon Driven with Joystick |
| Night Vision | Mechanical IR Cut Filter |
SKU  | DWC-C223W |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, On Screen Display Menu, Privacy Masking, Wide Dynamic Range |
| Manufacturer | Digital Watchdog |
| NDAA | Compliant |
Camera Signal  | Analog, HD-AHD, HD-CVI, HD-TVI |
| Resolution | 1080p |
| Sensor Option | 1/3" CMOS |
| Lens Type | Not Included |
| Infrared Distance | Non Infrared |
| Durability | Indoor |
| Mount Type | Bracket Required |
| Voltage | 12vDC, 24vAC, Dual Voltage |
| Electronic Shutter | 1/30(25) – 1/30,000 |
| Gamma Correction | 0.45 ~ 0.75 |
| Image Device | 2.1MP 1/3” CMOS Sensor |
| Minimum Scene Illumination | F1.2 (30IRE): 0.02 Lux (Color) |
| Operating Humidity | Less than 90% (Non-Condensing) |
| Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Dimensions (W x H) | 4.71 x 2.31 x 2.44 inch (119.7 x 58.8 x 62 mm) |
| Power Consumption | DC12V: 2.45W , AC24V: 2.4W |
| Privacy Zone | 16 Privacy Zones |
| S/N Ratio | 55dB |
| Scanning System | Progressive Scan |
| Video Output | HD-Analog, HD-TVI, HD-CVI 2.1MP 1080p CVBS Analog up to 960H |
| Synchronization | Internal |
| Digital Noise Reduction | 3D, Off, Low, Middle, High |
| Automatic White Balance | Auto / Auto-Ex / Preset / Manual |
| Auto Gain Control | Max 60dB |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Mirror | Yes |
| On Screen Display Menu | Yes |
| Wide Dynamic Range | Yes |
| Privacy Masking | Yes |
| Motion Detection Tracking | Yes |
