Exacq S-36T-4U Rackmount 4U Storage Server, 36TB HDD
SKU
S-36T-4U
Model No
S-36T-4U
$20,086.00
Product Highlights
- Cost-effectively increase video storage without having to add recorders
- Monitor from exacqVision client interface, Enterprise System Manager, or exacqCloud
- Reduces the complexity of integrating and learning thirdparty storage solutions
- Archive video and audio with instant search capability
- Expands the storage up to 96 TB on 2U models and 240 TB on 4U RAID models
Speak to an expert
The Exacq S-36T-4U Rackmount 4U Storage Server is a high-capacity storage solution for video surveillance systems, offering 36TB HDD support and efficient archiving capabilities. With a blazing fast archiving rate of 1,500Mbps (2,000Mbps with an optional quad NIC) and a maximum storage capacity of 240TB in RAID configurations, this server meets the growing demands of data storage while maintaining reliability and ease of use.
Exacq S-36T-4U Key Features
- Cost-effective Storage: Easily increase video storage without needing additional recorders, lowering overall costs while expanding capacity.
- Simplified Integration: Preconfigured with exacqVision software, reducing the learning curve and complexity associated with third-party systems.
- Instant Video Archiving: Archive and search for video data effortlessly through the exacqVision client with user-defined rules to optimize network efficiency.
- Health Monitoring: Manage system health with alerts for hard drive or power supply issues through an intuitive interface, streamlining administration.
- Scalability: Support significant increases in storage, accommodating the evolving demands of digital surveillance with enterprise-class hard drives.
- Cybersecurity Compliance: NDAA-compliant design with robust measures against cyber threats, ensuring data integrity across devices.
Exacq S-36T-4U Detailed Specifications
| Feature | Details |
|---|---|
| Storage Capacity | 36TB HDD, expandable up to 240TB in RAID 6 models |
| Archiving Rate | 1,500Mbps (2,000Mbps with optional quad NIC) |
| Extended Storage Rate | 350Mbps |
| Drive Bays | 8 drive bays for maximum configuration |
| RAID Support | RAID 5 and RAID 6 options for redundancy and data safety |
| Network Interface | Triple Gb NIC for enhanced connectivity |
| Operating System | Ubuntu Linux 20.04 |
| Software | exacqVision storage software pre-installed |
| Warranty | 3-year hardware warranty and software updates |
SKU  | S-36T-4U |
|---|---|
| Manufacturer | Exacq |
| NDAA | Compliant |
| Harddrive Size | 36TB |
| Protocols | EXACQ Protocols |
| Features | Audio, Redundant Power, Supports the Full HD Output (HDMI) |
| Operating temperature | 40° - 95° F (4.5° - 35° C) |
| Dimensions | 7.0” x 16.875” x 27” (17.8 x 42.9 x 68.7 cm) |
| Voltage | 120/240 VAC auto-sensing |
USB  | 2 x USB 3.2, 4 x USB 3.1, 2 x USB 2.0 |
| Audio | Yes |
| Redundant Power | Yes |
| Supports the Full HD Output (HDMI) | Yes |
