Panasonic WV-S1136A 2 Megapixel Network Indoor Box Camera
SKU
WV-S1136A
Model No
WV-S1136A
$750.00
Product Highlights
- 2MP Indoor box camera
- Up to 2 Edge AI analytic apps
- Built-in FIPS 140-2 Level 3 Certified Secure Element (Edge Lock® SE050F NXP® Semiconductors)
- NDAA Compliant
Speak to an expert
The WV-S1136A from Panasonic is an S-series 2MP network camera with advanced features that enhance security and surveillance capabilities. Equipped with an AI engine, this camera provides excellent performance and reliability, making it ideal for various indoor applications.
Panasonic WV-S1136A Camera Features
- 2MP Indoor Box Camera: Delivers high-resolution images for enhanced clarity and detail in surveillance.
- Up to 2 Edge AI Analytic Apps: Supports advanced analytics, allowing for real-time data processing and increased security measures.
- Built-in FIPS 140-2 Level 3 Certified Secure Element: Ensures data integrity and security with a secure element from NXP® Semiconductors, protecting against potential vulnerabilities.
- NDAA Compliant: Meets the National Defense Authorization Act requirements, ensuring compliance with secure investment in networking equipment.
Detailed Camera Specifications for Panasonic WV-S1136A
| Camera Type | 2 Megapixel Network Indoor Box Camera |
| Resolution | 1920 x 1080 pixels |
| AI Features | Supports up to 2 Edge AI analytic apps |
| Security | Built-in FIPS 140-2 Level 3 Certified Secure Element |
| Compliance | NDAA Compliant |
| Networking | IP Network connectivity |
| Dimensions | Compact and user-friendly design |
SKU  | WV-S1136A |
|---|---|
| Features | Audio, Auto Gain Control, AI Analytics, Automatic White Balance, Back Light Compensation, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Panasonic |
| NDAA | Compliant |
| Connection Type | Wired |
Infrared Distance  | Non Infrared |
| Resolution | 2 Megapixel |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, JPEG, H.265 |
| Durability | Indoor |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | The level can be set in the range of 0 to 11. |
| Dimensions (W x H) | 75 mm (W) x 57 mm (H) x 146 mm (D) {2-15/16 inches (W) x 2-1/4 inches (H) x 5-3/4 inches (D)} (excluding lens / power cord plug) |
| Electronic Shutter | [60fps mode] 1/60 Fix to 1/10000 Fix, [30fps/15fps mode] 1/30 Fix to 1/10000 Fix [50fps mode] 1/50 Fix to 1/10000 Fix, [25fps/12.5fps mode] 1/25 Fix to 1/10000 Fix |
| Image Device | Approx. 1/2.8 type CMOS image sensor |
| Minimum Scene Illumination | 0.006 lx (30IRE, F1.2, 1/30s, AGC:11)* 0.008 lx (50IRE, F1.2, 1/30s, AGC:11) 0.0005 lx (50IRE, F1.2, 16/30s, AGC:11) |
| Operating Humidity | 10 to 90 % (no condensation) |
| Operating Temperature | -10 °C to +50 °C (14 °F to 122 °F) |
| Power Consumption | DC12 V 480 mA, Approx. 5.8 W DC48 V 130 mA, Approx. 6.3 W (Class 2 device) |
| Privacy Zone | On / Off, Up to 8 zones available |
| Digital Noise Reduction | The level can be set in the range of 0 to 255. |
| Motion Detection Tracking | On / Off, 4 areas available |
| Back Light Compensation | BLC, HLC |
| Automatic White Balance | ATW1/ ATW2/ AWC |
| Audio | Yes |
| Auto Gain Control | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
