Luminys N4B-8VA2 8 Megapixel Network IP LumiNightKing Bullet Camera with 2.8mm Lens
- 8MP Bullet Housing
- 2.8 mm Lens
- AI-ISP
- White-Light LEDs
- Video Content Analytics: Line Crossing, Intrusion
Luminys N4B-8VA2 Camera Features
The N4B-8VA2 is part of Luminys’s Mainstream series of security devices. Mainstream series devices are designed with a suite of advanced LumiTechnologies to meet the needs of today’s evolving security market.
Equipped with LumiNightKing technology, this camera provides flexible and reliable full-color video in near-dark conditions. It supports covert monitoring with no LEDs or 24/7 white-light LEDs for deterrent monitoring. This camera is also designed with LumiPolarPro and LumiDesertPro technologies to withstand extreme environments. It has both 12 VDC and PoE (Power over Ethernet) for flexible installation.
LumiNightKing cameras are built for mission-critical surveillance in challenging environments such as industrial facilities, transportation hubs, night clubs, and outdoor perimeters. Their dual purpose capability makes the series ideal for security applications that want a discrete camera to preserve the ambiance of a scene and for scenes that need a visible presence from continuous white-light LEDs throughout the night.
Features
- 8MP Bullet Housing: Provides high resolution for clear surveillance footage.
- 2.8 mm Lens: Offers wide-angle views for comprehensive coverage.
- AI-ISP: Enhances video quality and reduces noise for superior clarity.
- White-Light LEDs: Ensures visibility and acts as a deterrent in low-light conditions.
- Video Content Analytics: Includes Line Crossing and Intrusion detection for proactive security measures.
- iMD: Intelligent Motion Detection to minimize false alarms.
- LumiPolarPro and LumiDesertPro: Built to operate in extreme temperatures, making it reliable in various environments.
Luminys N4B-8VA2 Detailed Specifications
| Feature | Details |
|---|---|
| Camera Type | 8MP Bullet Camera |
| Lens Type | 2.8 mm Wide Angle Lens |
| AI Integration | AI-ISP for improved image quality |
| Lighting | White-Light LEDs for enhanced night visibility |
| Analytics | Line Crossing and Intrusion detection |
| Intelligent Detection | iMD for accurate motion alerts |
| Environmental Resistance | LumiPolarPro and LumiDesertPro technologies |
| Power Options | 12 VDC and Power over Ethernet (PoE) |
SKU  | N4B-8VA2 |
|---|---|
| Features | Audio, Auto Gain Control, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Luminys |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 8 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Ceiling, Pole, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 220.1 mm x 87.4 mm x 78.8 mm (8.7 in. x 3.4 in. x 3.1 in.) |
| Electronic Shutter | Automatic, Manual 1/3 s to 1/100,000 s |
| Image Device | 1/1.8-in. 8MP Progressive CMOS |
| Minimum Scene Illumination | Color: 0.0003 lux at F1.0 |
| Operating Humidity | < 95% RH (Non-Condensing) |
| Operating Temperature | -40 to 60 °C (-40 to 140 °F) |
| OSD Menu | 12 VDC: Maximum: 6.1 W, Normal: 2.3 W , PoE: Maximum: 7.4 W, Normal: 3.2 W |
| Privacy Zone | IPv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1X, RTSP, DDNS, P2P, SMTP, RTMP, PPPoE, UPnP, SNMP, Bonjour, QoS, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, ARP, NTP, Multicast, NFS |
| Protocols | > 56 dB |
| Video Output | IP67 |
| Synchronization | 3D NR |
| Digital Noise Reduction | Supported |
| Processor | Horizontal: 110° , Vertical: 59° , Diagonal: 131° |
| Rotation Angle | Supported with Alarms for Vehicles and Humans |
| Back Light Compensation | 0° to 360° |
| Automatic White Balance | Yes |
| IR Distance | 50m/164ft |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
| Digital Zoom | Yes |
