InVid ELEV-C5LIR28N 5 Megapixel IR Fixed Outdoor Low Profile Dome with 2.8mm Lens
SKU
ELEV-C5LIR28N
Model No
ELEV-C5LIR28N
$92.00
Product Highlights
- 5-2 Megapixel Field Selectable**
- All-in-One Technology (TVI/AHD/CVI/Analog 960h)
- Fixed Lens
- True Day/Night
- True WDR
Speak to an expert
The ELEV-C5LIR28N from InVid is a state-of-the-art 5 Megapixel IR fixed outdoor low profile dome camera equipped with a 2.8mm lens, delivering exceptional video quality and advanced features designed for reliable surveillance in various environments.
InVid ELEV-C5LIR28N Camera Features
- 5 Megapixel Field Selectable: Offers flexibility for varying resolutions, ensuring clear and detailed imaging for different applications.
- All-in-One Technology (TVI/AHD/CVI/Analog 960h): Compatibility with multiple formats makes installation simple and versatile, accommodating various existing systems.
- Fixed Lens: The 2.8mm lens provides a wide-angle view, perfect for monitoring larger areas without sacrificing image clarity.
- True Day/Night: Automatically switches between day and night modes for optimal performance in low-light conditions, enhancing security 24/7.
- True WDR: Wide Dynamic Range technology balances bright and dark areas in a scene, ensuring all details are captured even in challenging lighting.
- 30’ Smart IR Range: Infrared capabilities allow for clear images up to 30 feet in complete darkness, making it ideal for night surveillance.
- Up The Cable (UTC) Function: Simplifies camera control and configuration through the existing coaxial cable, reducing installation complexity.
- IP66 Weather Resistant: Rugged construction protects against dust and water, ensuring long-lasting performance in outdoor settings.
- 12VDC Only Operation: Streamlined power requirements make it easy to integrate into your surveillance system.
- Through InVid Tech DVR: Access a free app, as well as CMS & MAC client for easy remote viewing and management.
InVid ELEV-C5LIR28N Detailed Specifications
| Model | ELEV-C5LIR28N |
| Resolution | 5 Megapixels |
| Lens Type | Fixed 2.8mm |
| Field of View | Wide-angle |
| Night Vision | 30’ Smart IR |
| Weather Resistance | IP66 |
| Power Supply | 12VDC |
| Advanced Features | True Day/Night, True WDR, UTC Function |
| Compatibility | TVI/AHD/CVI/Analog 960h |
| Remote Access | Free App, CMS & MAC Client |
SKU  | ELEV-C5LIR28N |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Weather Resistant, Wide Dynamic Range |
| Manufacturer | InVid |
| NDAA | Compliant |
Camera Signal  | Analog, HD-AHD, HD-CVI, HD-TVI |
| Resolution | 5 Megapixel |
| Sensor Option | 5 MP CMOS |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Infrared Distance | 61~100 Feet |
| Durability | Weather Resistant |
| Mount Type | Ceiling, Wall |
| Voltage | 12vDC |
| Image Device | 1/2.8” 5Mega-pixel Sony CMOS |
| Image Pixels-Effective | 2592(H)*1944(V) |
| IR Distance | 30m/98ft |
| Minimum Scene Illumination | 0Lux(10PCs led ON) |
| Operating Temperature | -22 °F+122 °F (-30℃+50℃) |
| Dimensions (W x H) | 3.87”×3.87×2.46” (98.4×98.4×62.5mm) |
| S/N Ratio | ≥54DB |
| Video Output | TVI:5MP 20/12.5 FPS, 4MP/2MP 30/25 FPS AHD:5MP 20/12.5 FPS, 4 MP / 2MP 30/25 FPS CVI:4MP 30/25 FPS, 2 MP 30/25 FPS CVBS” |
| Weatherproof | IP66 |
| Automatic White Balance | ATW (PRO default),Gray World Optional |
| Audio | Yes |
| Back Light Compensation | Yes |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Wide Dynamic Range | Yes |
| Auto Gain Control | Yes |
