Bogen V100 Power Vector Modular Input Amplifier, 100W

The V100 from Bogen is a power vector amplifier 100W with 8 module bays for a wide array of inputs and outputs. Modules are available for signal processing and inputs such as: balanced and unbalanced inputs; stereo or mono; telephone systems/PBXs; transformer-isolated; microphones; tone generator; and bridging. The Power Vector automatically senses each module and inserts it into the signal path. A 5-position barrier strip allows for 4/8ohm or 25/70V output loads. When you need an amplifier with flexibility and reliability, the Power Vector V100 is the obvious choice.

Bogen V100 Power Vector Amplifier Features

• Speaker Load Compatibility: Capable of handling 70V, 25V, 8-ohm, and 4-ohm speaker loads, ensuring versatility for various setups.
• Module Bays: 8 module bays allow for extensive customization with a wide selection of advanced plug-in modules (modules sold separately), enhancing functionality.
• Priority Levels: 4 levels of priority between modules facilitate effective management of different input sources.
• Signal Processing: 2 module bays dedicated to handling plug-in signal processing output modules, improving audio manipulation capabilities.
• Output Monitoring: 11-segment LED output level meter with Avg./Peak meter switch monitors output levels for optimal performance.
• Remote Volume Control: Motorized master volume control can be remotely operated for user convenience.
• Output Selection: Lockable switch allows the user to select between transformer-coupled outputs or direct low-impedance output based on needs.
• Speaker Connections: 5-position barrier strip with clamping washers provides reliable connections for speaker loads.
• Bridging Options: Bridging In/Out connector enables easy interconnection with other Power Vector amps and mixers.
• Enhanced Mute Access: External access to priority mute buses streamlines signal management during events.
• Independent Volume Control: Each of the eight module bays features independent volume control for tailored audio output.
• Clipping Indicator: Two-color LED for each channel signals input activity or clipping, assisting in setup and performance adjustments.
• Tone Control: Bass and treble control with bypass switch (located in module bay 6) enhances audio tuning options.
• Insert Jacks: Signal-processing insert jacks allow external equipment integration between pre-amp output and power amp input, broadening usage scenarios.
• Buffered Output: Pre-EQ, unbalanced, buffered output signal maintains high quality while accommodating additional external devices.
• AC Convenience Receptacle: Grounded, unswitched AC convenience receptacle with a 500W maximum capacity is provided for powering external equipment.
• Security Covers: 8 module security cover/filler plates included with the amplifier (PVMC) enhance safety and maintain aesthetic.
• Rack Size: Compact design with 2 rack spaces high (3-1/2") ensures ease of integration into existing setups.
• Safety Certification: Listed to UL Standard 60065 for U.S. and Canada, ensuring compliance with safety regulations.
