Bogen TPU60B Telephone Paging Amplifier, 60W

The Bogen TPU60B Telephone Paging Amplifier is a powerful and versatile solution for enhancing paging and background music in various environments. With 60 watts of power, it supports multiple input types for flexibility, features a variable music mute function for seamless transitions, and incorporates advanced audio enhancement technology for improved clarity and intelligibility. Ideal for office spaces, retail settings, and more, the TPU60B ensures clear communication while maintaining an enjoyable auditory experience.

Bogen TPU60B Amplifier Features

• 60 watt model: Provides powerful amplification, suitable for larger spaces requiring clear paging capabilities.
• Inputs for 600-ohm balanced telephone line, Lo-Z balanced microphone, and background music: Offers versatile connectivity options to adapt to various audio sources.
• Music input (RCA jack or screw terminals): Simplifies integration with existing audio systems for easy installation.
• Integral automatic level control (ALC) circuit: Ensures consistent audio levels even with varying voice dynamics, enhancing paging clarity.
• Page from telephone and/or microphone: Provides flexibility in initiating pages from multiple sources.
• Signal-activated paging channel: Automatically mutes background music during a page to maintain focus on communication.
• Adjustable background music muting level: Allows customization of music levels during paging, ensuring optimal audio balance.
• Music returns to normal level gradually after a page: Prevents abrupt audio changes for a more pleasant listening experience.
• Audio Enhancement circuit: Improves sound clarity and reduces listener fatigue without increasing power usage.
• Separate controls for various audio functions: Provides enhanced control over page volume, music volume, night ringer, and other features.
• Bass and treble controls: Enables tailored sound adjustments to meet specific auditory preferences.
• Built-in night ringer: Activated by closure contacts or a 90V ring signal, ensuring notifications are heard after hours.
• Flexible output options: Includes balanced or unbalanced 16-ohm, 25V, 25V CT, and 70V outputs for diverse applications.
• VOX sensitivity level control: Prevents unintentional transmission of background noise during paging, ensuring clearer announcements.
• Thermal and electronic overload protection: Safeguards the unit and connected devices from damage due to excessive audio peaks.
• Bridging capabilities: Jacks provided for connecting additional TPU amplifiers for expanded audio coverage.
• Peak level indicator: Alerts when the amplifier approaches clipping for better audio management.
• 120V AC, 60 Hz power source: Standard power requirement for easy integration into existing electrical setups.
• Listed to UL Standard 60065: Certified for safety and compliance in both U.S. and Canadian markets.

Bogen TPU60B Detailed Specifications
