Louroe Electronics LE-288 4 Zone Audio Interface Adapter
SKU
LE-288

Louroe Electronics Model IF-4

Louroe Electronics LE-288 4 Zone Audio Interface Adapter

  • 3.5mm
  • Audio
Free shipping over $450
Model No
IF-4
$318.95
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • Compatible with all Louroe microphones
  • Contains terminal blocks for microphone connections
  • Supplies 12Vdc power to the microphones
  • Dual outputs (per microphone) to accommodate either on RCA input or 3.5mm input connection to DVR, IP Network Camera etc
  • Gain adjust (each output) to prevent overdriving or underdriving the audio signal

Overview

The LE-288 from Louroe Electronics is a Four-zone audio interface adapter designed for connecting up to four Louroe microphones with a DVR, PC sound card or other recording devices that have multiple audio inputs. The input side of the LE-288 has terminal blocks for receiving the wiring from the microphones. The output side has two types of output. RCA types & 3.5mm type outputs. The LE-288 also contain individual "audio out control" potentiometers for audio gain adjustment. The output from the Louroe microphone can be amplified to 10dB. A 12Vdc power supply (included) provides power to the Louroe microphone.

Louroe Electronics LE-288 Key Features

  • Compatible with all Louroe microphones: Ensures flexibility and integration with existing systems.
  • Contains terminal blocks for microphone connections: Streamlines setup and makes wiring easier.
  • Supplies 12Vdc power to the microphones: Eliminates the need for additional power sources.
  • Dual outputs (per microphone): Accommodates either RCA or 3.5mm connections, providing versatile compatibility.
  • Gain adjust for each output: Prevents overdriving or underdriving the audio signal, ensuring optimal sound quality.
  • 12 Vdc power supply included: Ready to use right out of the box.
  • RCA connector cables included: Conveniently packaged for immediate installation.
  • Audio test switch with indicator LED: Assures presence of audio for quick diagnostics.

Louroe Electronics LE-288 Detailed Specifications

Product TypeAudio Interface Adapter
Number of Zones4
Microphone CompatibilityAll Louroe microphones
Input Voltage12Vdc
Output TypesRCA, 3.5mm
Gain AdjustmentIndividual potentiometers per output
Audio Output AmplificationUp to 10dB
Power SupplyIncluded
Included AccessoriesRCA connector cables, audio test switch
LED IndicatorYes

Specifications

SKU  LE-288
Manufacturer  Louroe Electronics
# of Areas  4
