Bogen HTA125A Power Amplifier, 125 Watts

SKU
HTA125A
Model No
HTA125A
$599.77
Qty:
Product Highlights
    • Power MOSFET circuitry
    • Capable of continuous operation at rated output power
    • Frequency response ±1dB, 20 to 20,000 Hz at full rated output
    • Distortion less than 0.5% THD, 20 to 20,000 Hz
    • Multiple output voltages/impedances available

The HTA125A from Bogen is a HTA Power Amplifier are high performance units employing Power MOSFET technology. The unique characteristics of Power MOSFET circuitry make them ideally suited to power amplifier design, providing far superior performance and reliability compared to other types of transistors. They offer higher efficiency, reduced heat, simpler overall design, reduced size and weight. The HTA125A Model supplies 125 watts (RMS continuous output) at less than 0.5% total harmonic distortion from 20 to 20,000 Hz. An input signal of only 500mV is required for full rated output. The input impedances are: high-impedance (50k ohms) unbalanced; low impedance (500/600 ohms, balanced or unbalanced) with optional accessory transformer Model TL600. Line bridging can be achieved with optional transformer Model TL100. Residual hum and noise is at least 90 dB below rated output and the output regulation is better than 2 dB from no load to full load. The amps can drive a variety of load impedances. Outputs include 4 ohms, 8 ohms, 25VCT and 70 volts. The amplifiers are capable of safely driving any recommended load continuously. The HTA amps are thermally protected to prevent damage due to excessively high temperatures. Additional failure-preventive devices include overload limiting, short circuit protection, and a SloBlo fuse.

Features

  • Power MOSFET circuitry
  • Capable of continuous operation at rated output power
  • Frequency response ±1dB, 20 to 20,000 Hz at full rated output
  • Distortion less than 0.5% THD, 20 to 20,000 Hz
  • Multiple output voltages/impedances available
  • Automatic overload protection
  • Listed to UL Standard 60065 for US and Canada
SKU  HTA125A
Manufacturer  Bogen
Features CD PlayerNo
Features AM/FM TunersNo
Features MP3 or iPod DockNo
Watts125 Watts
# of Inputs  2
# of Outputs  4
There are no related videos.
SKU
HTA125A
Availability: In stock
