KJB ANDRE-DELUXE Andre Deluxe Handheld Broadband Receiver

The ANDRE-DELUXE from KJB is a cutting-edge handheld broadband receiver designed to detect known, unknown, illegal, disruptive, or interfering transmissions. Its wide frequency range of 10 kHz to 12 GHz and included accessories make it an essential tool for quickly and discreetly mitigating threats posed by electronic bugging devices. With advanced features like signal strength histograms, audio playback capabilities, and comprehensive post-investigation resources, the ANDRE-DELUXE meets the high demands of technical security professionals and RF enthusiasts.

Features

• RF DETECTOR: Sensitivity: -75 dBm for 3 GHz frequency -85 dBm for probes providing frequency at 500 MHz. Stepped attenuation control: 30 dB, 20 dB, 10 dB, Auto, off, ensuring high precision in detecting various transmissions.
• AUDIO: Built-in speaker and external headphones with adjustable volume control for clear audio feedback during investigations.
• DISPLAY: 3.5” (4 cm) capacitive touch screen for easy navigation and data visualization.
• INPUT/OUTPUT: USB data port for software upgrades and file transfer, facilitating seamless compatibility and accessibility.
• POWER: Input: USB internal charger; Batteries: 3400 mAh lithium-ion rechargeable battery (2 included), USB recharger; Run time: >5 hours (typical), ensuring reliability during extended usage.

KJB ANDRE-DELUXE Applications

• APPLICATIONS: Emissions detection of WiFi, Bluetooth, cell phones, illicit transmitters, interference detection, contraband detection in correctional facilities, RF research and development, and corporate security surveys.

KJB ANDRE-DELUXE Signal Features

• HISTOGRAM DISPLAY: Displays RF levels over user-selected time intervals, allowing detection of digital, analog, and burst signals with alert thresholds.
• SIGNAL INFORMATION AND BAND DETAILS: Automatically generates a signal list from the strongest signals, providing detailed information on signal classification.
• AUDIO MODE: Demodulates and plays back live analog audio, with recording capabilities for 10-second audio files and real-time signal strength visualization.
• POST-INVESTIGATION RESOURCES: Allows review of investigation data, including time charts, audio playback, and signal lists for comprehensive reporting.

KJB ANDRE-DELUXE Technical Specifications
