Hanwha Vision QRN-1630S-2TB 16 Channel PoE NVR, 2TB
SKU
QRN-1630S-2TB
Model No
QRN-1630S-2TB
$981.50
Product Highlights
- Up to 16 channels, 8 megapixel supported
- H.265, H.264, MJPEG codec supported
- 128Mbps network camera recording
- Plug & play by 16 PoE ports (POE Budget 130W)
- Maximum 2 HDDs (up to 10Tb each) supported
Speak to an expert
16 Channel PoE NVR, 2TB
- The QRN-1630S-2TB from Hanwha Vision is a powerful 16 channel PoE NVR equipped with a 2TB hard drive, designed for seamless video surveillance with high performance and ease of use. With support for up to 8 megapixel cameras and advanced recording capabilities, it ensures reliable and high-quality monitoring for various applications.
NVR Functions
Alarm Notification by E-mail
Compression Supported
DDNS Functionality
H.264 Compression
H.265 Compression
MJPEG Compression
Supports PTZ Control
Supports the Full HD Output (HDMI)
Two-way Audio
NVR Features
| Up to 16 channels, 8 megapixel supported | Maximum 2 HDDs (up to 10Tb each) supported |
| H.265, H.264, MJPEG codec supported | 128Mbps network camera recording |
| Plug & play by 16 PoE ports (POE Budget 130W) | |
| NDAA & FCC Compliant Model. |
Additional Hanwha Vision Products
SKU  | QRN-1630S-2TB |
|---|---|
| Manufacturer | Hanwha Vision |
| NDAA | Compliant |
| IP Channels | 16 Channels |
| Harddrive Size | 2TB |
| Protocols | Samsung protocols, ONVIF Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, MJPEG Compression, Supports PTZ Control, Supports the Full HD Output (HDMI), Two-way Audio |
Resolution  | 8MP |
| Compression | H.265, H.264, MJPEG |
| Bandwidth | Max. 128Mbps |
| Operating temperature | 0°C to +40°C(32℉ to 104℉ |
| Dimensions | 370.0 x 50.7 x 320 mm (14.6 x 2.0 x 12.6 inch) |
| Voltage | 100 ~ 240 VAC ±10%; 50/60 Hz |
| Power Consumption | Max. 200W(682 BTU with 2HDD, PoE ON) |
| Network | PoE RJ-45 16EA (LAN, 10/100), RJ-45 1ea (LAN/WAN 1Gbps) |
| SATA | SATA 2ea(up to 20TB) |
| USB | 2EA(Front 2 x USB 2.0) |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| MJPEG Compression | Yes |
