Hanwha Vision ARN-1610S 16 Channel PoE NVR, No HDD
SKU
ARN-1610S
Model No
ARN-1610S
was $362.02 Special Price $307.99
Product Highlights
- Up to 16 channels @ 8 megapixel supported
- H.265, H.264, MJPEG codec supported
- 80Mbps network camera recording
- Plug & play by 16 PoE ports
- Maximum 2 HDDs (up to 6Tb each) supported
Speak to an expert
16 Channel PoE NVR, No HDD
- The ARN-1610S from Hanwha Vision is a state-of-the-art 16 channel PoE NVR designed to provide high-performance video recording and management without the hassle of pre-installed HDDs. With support for up to 8 megapixels, advanced codecs, and seamless remote access, this NVR ensures a secure and efficient surveillance solution for any environment.
NVR Functions
Alarm Notification by E-mail
Compression Supported
DDNS Functionality
H.264 Compression
H.265 Compression
MJPEG Compression
Supports PTZ Control
Supports the Full HD Output (HDMI)
Two-way Audio
NVR Features
| Up to 16 channels @ 8 megapixel supported | Maximum 2 HDDs (up to 6Tb each) supported |
| H.265, H.264, MJPEG codec supported | HDMI/VGA local monitor |
| 80Mbps network camera recording | P2P service (QR code connect) for easy remote access with Wisenet Viewer & Wisenet Mobile |
| Plug & play by 16 PoE ports |
Additional Hanwha Vision Products
SKU  | ARN-1610S |
|---|---|
| Manufacturer | Hanwha Vision |
| IP Channels | 16 Channels |
| Harddrive Size | No HDD |
| Protocols | Samsung protocols, ONVIF Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, MJPEG Compression, Supports PTZ Control, Supports the Full HD Output (HDMI), Two-way Audio |
Resolution  | 8MP |
| Compression | H.265, H.264, MJPEG |
| Bandwidth | Max. 80Mbps |
| Operating temperature | 0°C to +40°C(32℉ to 104℉) |
| Dimensions | W370.0 x H44.0 x D320 mm (14.57" x 1.73" x 12.6") (1U) |
| Voltage | 100 ~ 240 VAC ±10%; 50/60 Hz |
| Power Consumption | Max 188.2W (2HDD, PoE On) |
| Network | PoE RJ-45(LAN, 10/100) 16 ea ,RJ-45 1ea (WAN, 1Gbps) |
| SATA | SATA 2ea(Max. 12TB) |
| USB | 2EA(Front 1 x USB 2.0, Rear 1 x USB 2.0) |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| MJPEG Compression | Yes |
