Interlogix VDR14120WDM Digital Video Receiver / Data Transceiver, MM Laser, 1 Fiber

SKU
VDR14120WDM
Interlogix VDR14120WDM Digital Video Receiver / Data Transceiver, MM Laser, 1 Fiber VDR14120WDM by Interlogix
Interlogix VDR14120WDM Digital Video Receiver / Data Transceiver, MM Laser, 1 Fiber VDR14120WDM by Interlogix
Model No
VDR14120WDM
$1,314.37
Qty:
Product Highlights
    • 10-Bit Digitally Encoded Video Transmission
    • Exceeds RS-250C Short-Haul Transmission
    • NTSC, PAL, SECAM Compatible
    • Full Color Compatibility
    • No In-field Electrical or Optical Adjustments Required

The VDR14120WDM is a professional digital video receiver and data transceiver from Interlogix that is suited for delivering simultaneous 10-bit broadcast quality transmission over a multimode/single-mode fiber. The VDR14120WDM data transceiver comes with support from CCTV manufacturers, full color compatibility, NTSC/PAL/SECAM formatting, exceeds short haul RS-250C transmission, as well as LED status indicators, and rack hot-swappable modules. The VDR14120WDM transceiver also features no infield electrical/optical adjustments, a 1.9 miles (3 km) distance range, plus automatic resettable fuses, and integrated WDM. This professional data transceiver is capable for being used within a large range of different applications, and is suited for promoting exceptional transmission properties for long range distances.

Features

  • 10-Bit Digitally Encoded Video Transmission
  • Exceeds RS-250C Short-Haul Transmission
  • NTSC, PAL, SECAM Compatible
  • Full Color Compatibility
  • Supports RS-232, RS-422, Sensormatic “Sensornet” or RS-485(2-wire or 4-wire) Data Interfaces
  • No In-field Electrical or Optical Adjustments Required
  • LED Status Indicators For Monitoring All Critical OperatingParameters
  • Tested and Certified by an Independent Testing Laboratory for Full Compliance with the Environmental Requirements (AmbientOperating Temperature, Mechanical Shock, Vibration, Humidity with Condensation, High-Line/Low-Line Voltage Conditions and Transient Voltage Protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment
  • Integrated WDM for Greater Reliability
  • Automatic Resettable Fuses on all Power Lines
  • Distances up to 31 Miles (51 km)
SKU  VDR14120WDM
Manufacturer  Interlogix
Fiber Optic Transmission use  Serial Data, Video
Channels  3 Channel
Connection Type  FC, SC, ST
Format  Multi-Mode
Mounting Options  Stand Alone, Surface Mount
