Alpha NC365B Pager System Transmitter/Control Unit, Use with NC397A Pocket Pagers

SKU
NC365B
Alpha NC365B Pager System Transmitter/Control Unit, Use with NC397A Pocket Pagers NC365B by Alpha
Alpha NC365B Pager System Transmitter/Control Unit, Use with NC397A Pocket Pagers NC365B by Alpha
Model No
NC365B
$6,881.00
Qty:

Product Highlights
    • Operates with NC300, NC300II, TC500 or NC110A/NC110N/NC150N/NC200N systems (requires NC377 series voltage interface adapter)
    • System covers a radius of up to one mile (site survey must be done to verify range)
    • 9600 baud serial input, 1200 baud transmit
    • Supports NC397A (and other) pocket pagers
    • 8 dry contact alarm inputs

The NC365B from Alpha is a Transmitter/Control Unit (on-site paging system) receives alphanumeric messages and patient call information via serial interface and transmits the information directly to the NC397A pocket pagers. Information is sent to the transmitter at 9600 baud to minimize bottlenecks. Call type and location are determined by the system supplying information to the transmitter. The NC365B Paging System Transmitter/Control Unit is pre-programmed for use with the NC300 (or NC300II) nurse-call systems, or TC500 emergency-call systems. The Unit is designed for on site paging requirements only and not for long range. The range of the system will largely depend on the site and location of the transmitter unit. To determine the exact range and coverage of the transmitter, a site survey must be done. For estimation purposes of a properly located NC365B, a range of up to one mile can be expected (line of sight), under ideal conditions. Battery back-up also available, by using the model# BA365K kit.

Features

  • Operates with NC300, NC300II, TC500 or NC110A/NC110N/NC150N/NC200N systems (requires NC377 series voltage interface adapter)
  • System covers a radius of up to one mile (site survey must be done to verify range)
  • 9600 baud serial input, 1200 baud transmit
  • Supports NC397A (and other) pocket pagers
  • 8 dry contact alarm inputs
SKU  NC365B
Manufacturer  Alpha
Frequency  457.55 MHz
