American Fibertek MX-50-FX-1F-ST One Fiber/Port Module FX Multimode ST Connector

The American Fibertek transmits and receives (2) copper 10/100 BaseT Ethernet signals at the RJ45 ports and (2) optical 100 Base-FX over 1 or 2 multimode fibers. The system is comprised of two or more units forming a communications link. The system is designed to be completely transparent with auto negotiation features which automatically configure the unit for the correct speed (10/100BaseT). Auto MDI/MDIX operation eliminates the potential need for crossover cables. Diagnostic indicators provide a quick visual indication of system status.

Features

• Complete Fiber Optic to Twisted Pair Media Interface
• Drop and Repeat Capability
• Auto MDI / MDIX Detection
• Auto Negotiate 10/100 Ports
• Link and Activity Indicators for UTP and Fiber Ports
• Multimode Fiber
