Comnet FVT8018M1 8-Channel Digitally Encoded Video Transmitter + 8 Bi-directional Data Channels, MM

SKU
FVT8018M1
Comnet FVT8018M1 8-Channel Digitally Encoded Video Transmitter + 8 Bi-directional Data Channels, MM FVT8018M1 by Comnet
Comnet FVT8018M1 8-Channel Digitally Encoded Video Transmitter + 8 Bi-directional Data Channels, MM FVT8018M1 by Comnet
Model No
FVT8018M1
$4,541.57
Qty:
Product Highlights
    • 10-bit digital video transmission: transmits 8 real-time color video signals and 8 bi-directional data signals on one optical fiber
    • Supports RS232, RS422, and 2 or 4-wire RS485
    • Exceeds all requirements for EIA RS-250C short-haul transmission
    • Compatible with all NTSC, PAL, or SECAM CCTV camera systems
    • Voltage transient protection on all power and signal input/output lines provides unconditional protection from power surges and other voltage transient events

The ComNet FVT8018(M)(S)1 Series transmits eight (8) channels of 10-Bit Digital Video along with eight (8) channels of bi-directional data over one single mode or multimode optical fiber. The video quality exceeds RS-250C for short-haul video transmission. This equipment is environmentally hardened and suitable for use in unconditioned roadside or out-of plant installations. The FVT8018 is compatible with NTSC, PAL and SECAM video transmission protocols and supports bi-directional RS232, 422 and RS485 (2 & 4 Wire) data. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are required. Bi-Color (RED/GREEN) LED indicators are provided to indicate the status of the system, video and data. Packaged in the exclusive ComNet ComFit housing, these units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.

Features

  • 10-bit digital video transmission: transmits 8 real-time color video signals and 8 bi-directional data signals on one optical fiber
  • Supports RS232, RS422, and 2 or 4-wire RS485
  • Exceeds all requirements for EIA RS-250C short-haul transmission
  • Compatible with all NTSC, PAL, or SECAM CCTV camera systems
  • Tested and certified by an independent laboratory for full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low-line voltage conditions and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment
  • Voltage transient protection on all power and signal input/output lines provides unconditional protection from power surges and other voltage transient events
  • Robust design ensures extremely high reliability in unconditioned out-of-plant environments
  • Bi-color (Red/Green) LED status indicators provide rapid indication of critical operating parameters
  • Hot-swappable rack modules
  • Interchangeable between stand-alone or rack mount use – ComFit
SKU  FVT8018M1
Manufacturer  Comnet
Fiber Optic Transmission use  Serial Data, Video
Channels  8 Channel
Connection Type  ST
Format  Multi-Mode
Mounting Options  Rack Mount, Surface Mount
