Comnet CNFE2004S1B 2 Channel 10/100 Mbps Ethernet 1550/1310nm

The ComNet Ethernet CNFE2004S1B media converter is two-channel Ethernet electrical to optical media converters. These auto-negotiating devices accept two 10/100 Mbps electrical inputs and convert this to a single 100 Mbps optical output. This media converter is available as singlemode and one fiber SC optical connector. The ComNet exclusive Demux feature allows for port isolation, replicating two media converters over one fiber. The ComNet exclusive Mux feature prevents network video flooding of multicast traffic with DIP switch selection of the fiber port as a dedicated uplink path.

ComNet CNFE2004S1B - Key Features

• 10/100 Mbps Ethernet: Ensures high-speed connectivity for data networks.
• Auto-Negotiation: Electrical ports automatically adjust for 10 Mbps or 100 Mbps speeds, supporting full duplex or half duplex data, allowing for flexible network configurations.
• Optical Port Capacity: Supports 100 Mbps full duplex data to handle significant bandwidth needs.
• Automatic MDI/MDI-X: Simplifies cable management by automatically configuring the connection type.
• Long Distance Capability: Distances up to 3 km (2 mi) Multimode and 20 km (12 mi) Single Mode, enabling extensive network reach.
• Link Fault Pass-Through: Automatically indicates copper port failures via state changes on the optical port, ensuring timely network maintenance.
• Compliance with Environmental Standards: Meets NEMA TS-1/TS-2 and Caltrans specifications for durability in harsh conditions.
• SC Optical Connectors: Provides reliable and secure fiber connections.
• 1 Fiber Design: Efficiently utilizes fiber for effective data transmission.
• Voltage Transient Protection: Safeguards against power surges to protect the device and connected network.
• No Optical Adjustments Required: Simplifies installation and reliability without in-field tuning.
• Remote Link Failure Detection: Full-size units feature a contact closure output for easy monitoring of link integrity.
• Hot-Swappable Rack Module: Standard size allows for quick replacements without downtime.
• ComFit Design: Interchangeable between stand-alone or rack mount uses for versatile deployment.
