Comnet CNFE2004S1APoE/HO/M 2 Channel 10/100 Mbps Ethernet Electrical To Optical Media Converter

The ComNet Ethernet CNFE2004S1APoE/HO/M media converter is a high-performance solution designed to convert Ethernet electrical signals to optical signals while providing Power over Ethernet (PoE+) functionality. With its dual-channel capability, it efficiently handles two 10/100 Mbps electrical inputs, transforming them into a single 100 Mbps optical output. This device offers robust features such as the exclusive Demux and Mux functionalities, ensuring network stability and efficiency even in demanding environments.

ComNet CNFE2004S1APoE/HO/M Unique Features

• 60W PoE+: Provides Power over Ethernet, allowing connected devices to operate without separate power supplies.
• 10/100 Mbps Ethernet: Supports standard Ethernet speeds for versatile networking capabilities.
• Dual Electrical Ports: Two 10/100 BASE-T/TX ports facilitate multiple connections for enhanced network flexibility.
• Optical Output: Offers a single 100 BASE-FX optical port for long-distance data transmission.
• Auto-Negotiation: Automatically adjusts to the best speed and duplex settings for optimal performance.
• Distance Capabilities: Achieves transmission distances of up to 20 km (12 miles) using single-mode fiber.
• Link Fault Pass-Through: Alerts users to the status of ports, enhancing monitoring and maintenance.
• Environmental Compliance: Meets NEMA TS-1/TS-2 and Caltrans Specifications, ensuring durability in various environmental conditions.
• SC Optical Connector: Standardized optical connection type for compatibility with various systems.
• Voltage Transient Protection: Safeguards against power surges and other electrical anomalies.
• No Optical Adjustments Needed: Simplifies setup and maintenance with factory calibration.
• Remote Link Failure Detection: Alerts users to potential issues through contact closure output.
• Hot-Swappable Design: Facilitates quick replacement with minimal downtime.
• Interchangeability: Flexible installation options for stand-alone or rack mount use.
• IEEE 802.3 Compliance: Ensures compatibility with existing network standards.

ComNet CNFE2004S1APoE/HO/M Specifications
