Comnet CNFE2003S2 Standard Mount 10/100 Mbps DC-Only Media Converter

The ComNet Ethernet CNFE2003S2 media converter is an advanced solution for converting two-channel Ethernet electrical signals into a robust optical output. With its auto-negotiating capabilities, it supports 10/100 Mbps electrical inputs while providing a seamless 100 Mbps optical output. This media converter features exclusive technologies like Demux for port isolation and Mux to mitigate network video flooding, making it ideal for a variety of networking environments.

ComNet CNFE2003S2 Media Converter Features

• 10/100 Mbps Ethernet: Provides flexibility in network speed options, ensuring compatibility with various devices.
• 2 - 10/100 BASE-T/TX electrical ports: Dual electrical connections enhance device connectivity and functionality.
• 100 BASE-FX optical port: Ensures high-speed optical transmission for reliable network performance.
• Electrical ports support Auto-Negotiation: Automatically configures optimal operating modes, simplifying setup and enhancing efficiency.
• Optical port supports 100 Mbps full duplex data: Guarantees high data transfer rates for demanding applications.
• Automatic MDI/MDI-X crossover: Eliminates errors during setup by adapting to network conditions automatically.
• Distances up to: 3 km (2 mi) Multimode and 20 km (12 mi) Single Mode: Provides versatile options for different networking requirements.
• Link Fault Pass-Through feature: Enhances network reliability by indicating issues on copper ports to the head-end.
• Environmentally compliant: Meets NEMA TS-1/TS-2 and Caltrans specifications for resilience against environmental factors.
• SC optical connector: Ensures a secure and efficient optical connection.
• 2 fibers design: Provides a simple and effective solution for media conversion.
• Voltage transient protection: Safeguards devices from power surges and voltage spikes.
• No in-field optical adjustments required: Simplifies installation and maintenance processes.
• Contact closure output: Allows remote link failure detection for proactive network management.
• Hot-swappable rack module: Facilitates easy replacement without service interruption.
• Interchangeable design: Offers flexibility for standalone or rack mount configurations.
• IEEE 802.3 compliant: Ensures standard compliance for reliable networking.

ComNet CNFE2003S2 Media Converter Specifications
