Pelco CM9760-CDU-T CM9760 Matrix Code Distribution Unit

The CM9760-CDU-T is a high performance matrix code distribution unit from Pelco which is specially manufactured to offer high operation within a system that uses any RS-422 serial communications. The CM9760-CDU-T matrix code is able to offer up to 16 channels of RS-244 transmission only, and is designed to be used for the installation of dome and pan/tilt receivers in a home run or star configuration. The CM9760-CDU-T matrix code also features 16 x 3 point screw terminal connectors, and provides up to 16 driver outputs for the continuous monitoring of standby and active CC1s.

Pelco CM9760-CDU-T Features

• Two 8-Position, RJ-45 Parallel Connectors: Provide an input from a controller and an output for an additional daisy-chained CDU unit, enhancing system scalability.
• Sixteen 3-Position Screw Terminal Connectors: Used to output 16 RS-422 transmit-only code lines, ensuring robust and reliable data transmission.
• Home Run (Star) Wiring Capability: Allows for home run (star) type wiring of PTZ data lines, simplifying installation and improving system organization.
• Standard 100-240 VAC Input: Operates on a wide range of voltages (50/60 Hz auto-ranging), making it versatile for different power environments.
• 16 Driver Outputs: Provides 16 driver outputs, allowing for continuous monitoring of standby and active CC1s for enhanced operational oversight.

Pelco CM9760-CDU-T Detailed Specifications
