MuxLab 500970-UTP SFP Module, UTP 30m

The MuxLab Copper Transceiver Module offers a reliable and high-performance solution for bi-directional communication over copper cabling. Designed to support high-speed 10Gigabit Ethernet links over Cat 6a/7 cable, this module provides exceptional data transfer capabilities while ensuring low power consumption and minimal EMI emissions.

MuxLab Copper Transceiver Module Features

• Supports Links: Up to 30m using Cat 6a/7 Cable, enabling fast data transfer over medium distances.
• MSA Compliance: SFF-8431 and SFF-8432 standards ensure compatibility with industry devices.
• Standard Compliance: IEEE 802.3az compliant for energy-efficient Ethernet operation.
• Power Efficiency: Low power consumption with a maximum of 2.5W @ 30m, making it cost-effective.
• EMI Cancellation: Fast retrain EMI cancellation algorithm enhances signal integrity.
• EMI Emissions: Low EMI emissions ensure compliance with industry standards.
• I2C Interface: 2 wire serial interface for seamless access to serial ID and PHY registers.
• Auto-Negotiation: Automatically negotiates with other 10GBase-T-NC PHYs for optimal connection.
• Wiring Correction: Automatic detection and correction of wiring and polarity swaps simplifies installation.
• Durable Housing: Robust die-cast housing provides protection and longevity.
• Ejector Mechanism: Bail latch style ejector mechanism for easy module insertion and removal.
• Cable Support: Compatible with both unshielded and shielded cables for versatile deployment.

Detailed Specifications for MuxLab Copper Transceiver Module
