Kramer 20-004590 4x4 4K60 4:4:4 HDMI + Audio Seamless Matrix Switcher

The MTX3−44−HSA is a high−quality scaler−based matrix with four HDMI inputs independently routable to four HDMI outputs. The video scaling processor provides a seamless switching experience. Each HDMI output supports down− or up−scaling to account for sink/source capability differences. The integrated audio matrix, with two analog audio inputs and two analog audio outputs, supports routing of any digital or analog audio source to sink, including ARC (Audio Return Channel) sources.

Features

• Flexible and Safe Matrix Routing - Seamless, ultra−fast switching transitions for an enhanced end−user presentation experience
• HDMI Signal Switching - HDCP 2.3 and HDMI 2.0b compliant
• OSD - Displays a convenient On−Screen Display INFO screen showing the unit’s IP settings, firmware version, video information, and more
• IP Gateway Support - CEC control messages to sinks or sources may be defined and generated using the IP control gateway mechanism
• I−EDIDPro™ Kramer Intelligent EDID Processing™ - Individual EDID management per input for capturing and storing EDID from output−connected displays or custom files
• Intelligent EDID handling and processing ensures plug−and−play operation for HDMI source and display systems
• Audio Embedding and De−embedding - Includes 2 analog balanced stereo inputs and 2 analog balanced stereo outputs for flexible integration with professional audio systems
• Auto−Output Shutdown - Automatically sends a CEC command and shuts down the output display when no input signal is detected for a specified period
• Automatic Display Wake−Up - The display is turned on again when the input signal returns
• Simple Control - Controlled over secured IP integrated web GUI and/or by any controller supporting Kramer’s P3K API commands
• Front−Panel Control - Simple and intuitive backlit buttons allow manual operation of the device
• Compact Size and Easy Installation - 1/2 19” enclosure for rack mounting in a half−1U rack space with included rack ears
• Secured Web−UI Operation - User credentials authentication provides secured web−UI access and operation
