Optex SIP-3020WF Wireless Ready 100' X 65' Superior Intelligent PIR Detector
- Three dual pyro-elements with patented Double Conductive Shielding
- Detection of ambient temperature and illuminance for automatic sensitivity management
- Advanced detection algorithm
- Anti-rotation with 3-axis accelerometer
- Anti-masking with Active infrared technology
The SIP-3020WF is a wireless-ready 100' x 65' superior intelligent high powered PIR detector from Optex that is able to provide and deliver high operation within many applications to produce additional safety and security options for all individuals. The SIP-3020WF wireless PIR detector comes with ambient temperature and luminance detection for sensitivity management, adjustable alarm interval times, reinforced polycarbonate housing, 3 Pyro-Elements with double conductive shielding, anti-masking with photo-beam, as well as a 30 x 20m coverage range, and advanced detection algorithm. The SIP-3020WF PIR detector also features anti-rotation with a 3 axis accelerometer, a detection range selector, a sensitivity selector, a detection logic selector, plus a durable and rugged construction. This professional PIR detector also features advanced operation and is able to provide resistance against false alarms to reduce un-required triggering of a system when it isn't required. Please also purchase the AFV-1 & AWT-3 - they would be Required for Proper Installation.
Optex SIP-3020WF Camera Features
- Three Dual Pyro-Elements: Provides enhanced sensitivity and accuracy in detecting motion due to patented Double Conductive Shielding.
- Ambient Temperature and Illuminance Detection: Automatically adjusts sensitivity levels based on environmental factors for optimal performance.
- Advanced Detection Algorithm: Minimizes false alarms by intelligently processing detection data.
- Anti-Rotation with 3-Axis Accelerometer: Ensures stable positioning and reliable operation regardless of installation angle.
- Anti-Masking with Active Infrared Technology: Prevents tampering and obstruction, enhancing security.
- Sensitivity Selector: Offers independent adjustments for near and far detection areas to tailor the coverage.
- Detection Logic Selector: Facilitates custom detection strategies to suit different environments and needs.
- Detection Range Selector: Allows for precise configuration of the detection area up to 30 x 20m.
- Independent N.C. and N.O. Outputs: Offers flexible integration options with existing alarm systems.
- Reinforced Polycarbonate Housing: Provides a durable and long-lasting product that withstands various environmental conditions.
Optex SIP-3020WF Detailed Specifications
| Product Type | Wireless-Ready PIR Detector | ||||||||
| Coverage Area |
