Bosch RSS-24MCC-FW Ceiling-Mount Strobe, Square, White
SKU
RSS-24MCC-FW
Model No
RSS-24MCC-FW
$44.33
Product Highlights
- UL Regulated voltage range of 16 V to 33 V using filtered DC or unfiltered FWR voltage
- Strobe produce 1 flash per second over the regulated voltage range
- ADA/NFPA/ANSI compliant
- Zero inrush above peak
- Fast installation with In and Out screw terminals using 18 AWG to 12 AWG (ISO 0.75 mm2 to 4 mm2) diameter wire
Speak to an expert
The Bosch RSS-24MCC-FW Ceiling-Mount Strobe offers versatile light intensity options and is designed for easy synchronization, making it an ideal choice for ensuring safety in various environments. Compliant with ADA and NFPA standards, this strobe provides reliable performance while accommodating multiple installation needs.
Bosch RSS-24MCC-FW Strobe Features
- UL Regulated Voltage Range: Operates between 16 V to 33 V, ensuring compatibility with various power sources.
- Flashing Rate: Produces 1 flash per second for effective signaling across diverse settings.
- Compliance: Meets ADA, NFPA, and ANSI standards for safety and accessibility.
- Zero Inrush: Designed to avoid inrush current issues, enhancing reliability during operation.
- Easy Installation: Features In and Out screw terminals compatible with 18 AWG to 12 AWG wire for quick setup.
Bosch RSS-24MCC-FW Detailed Specifications
| Model | Bosch RSS-24MCC-FW |
| Type | Ceiling-Mount Strobe |
| Light Intensity Options | 15 cd, 30 cd, 75 cd, 95 cd |
| Power Supply | 16 V to 33 V (filtered DC or unfiltered FWR) |
| Synchronization | Compatible with DSM-12/24-R and similar control panels |
| Flash Rate | 1 flash per second |
| Compliance Standards | ADA, NFPA, ANSI |
| Wire Compatibility | 18 AWG to 12 AWG (ISO 0.75 mm2 to 4 mm2) |
| Inrush Current | Zero inrush above peak |
SKU  | RSS-24MCC-FW |
|---|---|
| Manufacturer | Bosch |
| Type | Indoor |
| Siren Types | Strobes |
