GRI PBF-101T-B 3/8″ Diameter Plunger Switch, With Flange Open Loop, Brown

The GRI PBF-101T-B 3/8” Diameter Plunger Switch with Flange Open Loop in Brown is an innovative push button switch designed for reliable performance and easy installation. This switch replaces troublesome mechanical contacts with sealed contacts for longevity, while its press-fit design eliminates the need for additional mounting hardware, making it perfect for new installations or upgrades.

GRI PBF-101T-B Key Features

• Recessed magnetic contact: Ensures reliable activation while preventing accidental triggering.
• PB is 9/16” press fit: Allows for quick and easy installation without re-drilling.
• PBF dimensions: 3/4" x 1 1/2" with screw down flange for secure mounting.
• Adjustable screw plunger: Travel distance total of .270, with pre-travel at .090 ± .040 for customizable operation.
• 12” #22AWG leads: Comes with options for secure screw terminals for electrical connections.
• Custom leads available: Longer leads, zip cords, or jacketed cable can be requested for specific application needs.
• Hermetically sealed: Protects internal components, resulting in a longer service life.
• Plated contacts: Resists sticking or freezing, ensuring consistent operation.
• Includes spacers and mounting hardware: Ready to install right out of the box.
• Built-in E.O.L. Resistors and Diodes: Available upon request for added functionality.
• Available colors: Options include white and brown to suit various applications.

GRI PBF-101T-B Detailed Specifications
