GRI PB-101-B Push Button Plunger Switch, Without Flange Open Loop, Brown

The GRI PB-101-B Push Button Plunger Switch is designed to replace outdated mechanical contact systems, offering enhanced reliability and longevity. Its innovative press-fit design eases installation while the sealed reed switch technology ensures durable performance even in challenging environments. This versatile switch caters to various applications and installation requirements, providing an effortless upgrade to more efficient operation.

GRI PB-101-B Push Button Switch Features

• Recessed magnetic contact: Prevents accidental activation and enhances safety in operation.
• Press fit design: Measures 9/16”, allowing for simple installation without the need for re-drilling.
• Flange option available: PB is 3/4" x 1 1/2" with screw down flange, providing flexibility based on user requirements.
• Adjustable screw plunger: Total travel distance is .270, with adjustable pre-travel of .090 ± .040, ensuring precision in activation.
• Connection options: Comes with 12” #22AWG leads or screw terminals for versatile wiring setups.
• Customizable leads: Longer leads, zip cords, or jacketed cable can be requested for specific installations.
• Hermetically sealed: Protects internal components from contaminants, extending operational lifespan.
• Plated contacts: Resist sticking or freezing, ensuring consistent performance.
• Included hardware: Comes with spacers and mounting hardware for easy installation.
• E.O.L. Resistors and Diodes: Available upon request to enhance circuit performance and compatibility.

GRI PB-101-B Detailed Specifications
