Nascom N505AS-SW N505A Short Standard Switch

The N505AS-SW from Nascom is a N505A short standard switch designed for man doors. It combines an adjustable contact configuration with high-performance N35 NdFeB magnets for enhanced gap reliability. The closed loop design helps prevent false alarms resulting from door movement, and the innovative NO DEAD SPOT technology ensures maximum efficiency.

Nascom N505AS-SW Switch Features

• No Dead Spot Technology: Prevents false alarms by ensuring reliable activation even with minor door shifts.
• 24" Armored Cable Lead Protection: Safeguards the lead wires against damage, enhancing durability.
• Extra Wide Gap - N35 NdFeB Rare Earth Magnet: Provides superior performance with an extended activation distance.
• 36" 22AWG Wire Leads: Offers flexibility in installation, with a sufficient length to reach various connection points.
• Listed To UL634 Standard: Ensures compliance with stringent safety and reliability standards.
• Extruded Anodized (Type II) Aluminum: Enhances corrosion resistance and durability for long-lasting use.

Nascom N505AS-SW Additional Information

• Set: Standard Switch
• Color: Silver
• Flange: N
• Switch Size: L1.625" X W1.125" X H0.500"
• Termination: Armored Cable Over 22AWG UL 1061
• Circuit Configuration: Closed Loop
• Lead Length (in.): 24

Nascom N505AS-SW Detailed Specifications
