GRI MM-150RS-B Magnet, MM-9 Rare Earth

Larger than 3/8” but smaller than 3/4”, the GRI 150RS Series is a one-half inch diameter, flush mount contact. This 1/2” diameter design allows additional “working room” for extra wire, E.O.L. resistors, etc. Manufactured from a special polyvinyl material, the unique collar design will press into hollow core aluminum or vinyl clad windows with a “snap-in” fit. The 150RS can be ordered with 12” leads or screw terminals.

The GRI 150RS is paired with a matching 1/2” magnet case to offer the installer a 1/2”+ gap. The 150RS switches can also be paired with any of the wide selection of GRI magnets to help resolve difficult installation applications, including our MF-875.

Features

• Designed for hollow core doors and windows: Ensures a secure and reliable installation in various door and window types.
• Hole size allows for extra wire, etc.: Provides flexibility for wiring configurations, enhancing installation ease.
• 1/2"+ Standard gap: Accommodates compatibility with various magnets and installations.
• Hermetically sealed: Protects against dust and moisture, extending the lifespan of the product.
• Installs firmly in wood, vinyl and aluminum: Offers versatility across different materials for broad application.
• Recessed magnetic contact: Enables a low-profile installation, keeping aesthetics intact.
• Press or snap to fit: Simplifies the installation process, saving time and effort.
• 12” #22AWG leads or screw terminals: Allows for quick connections and versatile installation options.
• Longer leads, zip cord or jacketed cable upon request: Customization available to meet specific installation needs.
• Plated contacts resist sticking or freezing: Enhances reliability in varying environmental conditions.
• Built-in E.O.L. Resistors and Diodes upon request: Simplifies integration into security systems.
• Supervisory Loops available upon request: Provides additional functionality for enhanced security systems.
• Switches and Magnets available separately: Flexibility in purchasing options according to project needs.
• Colors: white and brown: Options for matching different decor styles and preferences.

GRI MM-150RS-B Magnet, MM-9 Rare Earth Specifications
