TRENDnet TI-S12024 24V 120W AC to DC DIN-Rail Power Supply with PFC Function

The TI-S12024 from TRENDnet is an AC to DC Industrial DIN-Rail Power Supply, model TI-S12024, supplies up to 120W (24V DC, 5A) of power to industrial equipment such as PoE switches, network cameras, and Wi-Fi access points. This DIN-Rail power supply comes with active PFC, an integrated DIN-rail mount, and overload current protection.

TRENDnet TI-S12024 Power Supply Features

• Industrial Power Supply: Integrated DIN-rail mount offers easy installation and stability in various environments.
• Power Output: Supplies up to 120W (24V DC, 5A) ideal for powering multiple devices simultaneously.
• High Efficiency: Achieves 91% efficiency, reducing energy costs and heat generation during operation.
• Peak Load Capability: Supports a 150% peak load capability, ensuring reliable performance under sudden power demands.
• Active PFC: Built-in Power Factor Controller (PF > 0.93) enhances the power supply's capability and efficiency.
• Cooling Method: Operates using free air convection, eliminating the need for additional cooling systems.
• Multiple Protections: Includes short circuit, overload, over voltage, and over temperature protections for enhanced safety.
• Approval: UL 508 approved, meeting strict safety and performance standards.
• DC OK Relay Contact: Built-in feature provides an alarm signal for system monitoring and responsiveness.
• Full Load Burn-In Test: 100% burn-in test conducted for reliability assurance before deployment.
• Wide Operating Temperature: Functions in temperatures ranging from -25° to 70° C (-13° to 158° F), suitable for diverse environments.

TRENDnet TI-S12024 Detailed Specifications
