Altronix T2DMK7F8D 8-Door Access and Power Integration Kit - Trove2DM2 with eFlow104NB, ACM8CB, VR6, PDS8CB
SKU
T2DMK7F8D
Model No
T2DMK7F8D
$1,019.72
Product Highlights
- 24VDC power supply/charger
- Accommodates up to eight (8) DMP 734/734N Wiegand modules
- CE Compliant
- Enclosure accommodates up to four (4) 12VDC/12AH batteries
Speak to an expert
Altronix T2DMK7F8D is a comprehensive 8-Door Access and Power Integration Kit designed for optimal security and flexibility. Featuring a Trove2 enclosure and a variety of power and distribution modules, this kit simplifies installations and improves management. With the capability to accommodate up to eight DMP Wiegand modules, it provides robust power solutions while ensuring compliance and security.
Altronix T2DMK7F8D Kit Features
- 24VDC Power Supply/Charger: Ensures reliable power delivery for consistent performance.
- Up to Eight DMP Modules: Supports multiple door access control, enhancing security in larger facilities.
- Convenient Knockout Configuration:
- Single 2” diameter knockout for easy wiring
- Sixteen double knockouts (1” and 0.75”) optimize installation convenience
- 16 AWG galvanized steel backplane aids in simplified board layout and management. - Supervision Features:
- Provides alerts for AC Fail, Low Battery, and Battery Presence ensuring system reliability.
- Low power shutdown feature enhances battery longevity. - CE Compliant: Adherence to European safety standards guarantees quality and reliability.
- Batteries Accommodated: Supports up to four 12VDC/12AH batteries for extended power supply during outages.
Altronix T2DMK7F8D Detailed Specifications
| Kit Model | T2DMK7F8D |
| Power Supply | 24VDC @ 10A |
| Number of Doors Supported | Up to 8 |
| Backplane Material | 16 AWG Galvanized Steel |
| Knockout Options | 1 x 2” diameter, 16 x (1” & 0.75”) |
| Battery Support | Up to 4 x 12VDC/12AH |
| Compliance | CE Compliant |
| Supervision Alerts | AC Fail, Low Battery, Battery Presence, Low Power Shutdown |
SKU  | T2DMK7F8D |
|---|---|
| Manufacturer | Altronix |
| Output Type | DC |
| Input Voltage | 120VAC |
| Number of Outputs | 8 |
| Output Protection | Fuse, PTC |
| Fire Alarm Interface | No |
| Battery Charging | No |
| Power Options | 10 amp @ 24VDC |
| Certifications | CE |
There are no related videos.
Write Your Own Review
Manuals & Specifications
T2DMK7F8D-Specsheet T2DMK7F8D-Installation-Instructions
