Securitron RB-4-12 Relay Board, 12 VDC

The Securitron RB-4-12 Relay Board is an essential tool for interlock installations and offers a simple yet effective solution for relay needs. This board enhances operational flexibility with multiple relay options, ensuring compatibility with various applications, such as shunting, interlocking, and reporting.

Securitron RB-4-12 Relay Board Features

• Versatile Usage: Adds relays for uses including shunting, interlocking, and reporting, enhancing installation flexibility.
• Customizable Connections: Offers individual coil connections with common negative or positive, allowing for easier integration into existing systems.
• Replacement Solution: Effectively replaces socket mount relays, providing a streamlined option for users looking to upgrade or replace older systems.
• High-Quality Components: Mounts 4 DPDT relays with 2 Amp contacts, ensuring reliable performance in demanding applications.
• Easy Installation: All dry contact connections are brought out on screw terminals for simplified wiring and setup.
• Low Power Consumption: Relays have low current coils (13mA at 12VDC), contributing to energy efficiency in your systems.
• Wide Compatibility: Allows operation from most LED drive outputs, ensuring it can be integrated into a range of environments.

Detailed Specifications for Securitron RB-4-12
