Samsung WRR-Q-A200W-48TB Wisenet WAVE Network Video Recorder, 48TB
- Preloaded and configured with Wisenet WAVE video management system
- 470 Mbps of recording throughput
- 48TB of Raw Storage
- SSD & 24/7 Duty Cycle SATA Drives
- Dedicated GPU for client application
The WRR-Q-A200W-48TB from Hanwha Vision is an affordable and reliable 2U rackmount solution for any entry-level deployment. 48TB of raw video-optimized storage is provided by 24/7 duty cycle SATA drives. The latest AMD EPYC Series Processor allows for high powered computing power, and 8GB of DDR4 RAM provides the system resources to scale as needed. The GPU provides enhanced client software performance. Powered by Microsoft Windows 10 IoT Enterprise. A dedicated solid-state drive for applications and the operating system enables fast boot and load times. Seven drive bays are available for video storage. Each server is pre-configured with Wisenet WAVE VMS and preloaded with 4 Professional licenses to ensure quick and easy deployment with minimum setup time.
Key Features
- Preloaded and configured with Wisenet WAVE video management system for quick and efficient deployment.
- 470 Mbps of recording throughput ensures high-quality video capture without interruptions.
- 48TB of Raw Storage provides ample space for extensive video recordings and archives.
- SSD & 24/7 Duty Cycle SATA Drives optimize performance and reliability for continuous recording.
- Dedicated GPU for client application enhances software performance and user experience.
- IPMI Management enables remote monitoring and management of the server for convenience.
- Includes USB mouse and keyboard for immediate usability right out of the box.
- Includes Sliding Rack Rail with Cable Management Arm for easy installation and organization.
- Supports Wisenet and ONVIF conformant IP cameras for versatile camera integration.
- Powered by Microsoft Windows 10 IoT Enterprise for a stable and secure operating environment.
Detailed Specifications
| Feature | Details |
|---|---|
| Model | WRR-Q-A200W-48TB |
| Storage Capacity | 48TB |
| Processor | AMD EPYC Series |
| RAM | 8GB DDR4 |
| Recording Throughput | 470 Mbps |
| Drive Bays | 7 |
| Operating System | Microsoft Windows 10 IoT Enterprise |
| Management | IPMI Management |
| Client GPU | Yes |
| Included Accessories | USB mouse, keyboard, Sliding Rack Rail with Cable Management Arm |
| Camera Support | Wisenet and ONVIF conformant IP cameras |
SKU  | WRR-Q-A200W-48TB |
|---|---|
| Manufacturer | Hanwha Vision |
| NDAA | Compliant |
| Harddrive Size | 48TB |
| Protocols | Onvif Protocols |
| Bandwidth | Up to 470 Mbps |
| Operating temperature | 50°F ~ 95°F (10°C ~ 35°C), 40°F ~ 104°F (5°C ~ 40°C) |
| Dimensions | 19" (482mm) x 28.25" (703mm) x 3.41" (86.8mm) |
| Voltage | 100 ~ 240V AC |
| Power Consumption | Maximum 788W |
| Network | 2 x RJ45 Gigabit Ethernet |
USB  | 2 x USB 3.0 (Rear), 2 x USB 2.0 (Front), 1 x USB 3.0 (Internal) |
| Memory | 8GB, 1 x 8GB DDR4 |
