TP-Link SG6428X Omada 24-Port Gigabit Stackable L3 Managed Switch with 4 10G Slots
SKU
SG6428X
Model No
SG6428X
$1,007.01
Product Highlights
- 24× Gigabit RJ45 ports and 4× 10 Gbps SFP+ slots
- 128 Gbps switching capacity per unit
- Physical stacking for built-in redundancy and performance
- L3 features: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay
- Security Strategies: ACL, Port Security, DoS Defend, 802.1X
Speak to an expert
The SG6428X from TP-Link is an high-performance L3 managed switch tailored for the convergence layer, featuring L3 routing, fast 10 Gbps wired speeds, stacking options, and redundant power supply modules. It includes 24× Gigabit RJ45 ports, 4× 10 Gbps SFP+ slots, physical stacking ability, and centralized management. Integrated with strong security and extensive management features, the SG6428X offers a dependable networking solution for SMBs, enterprises, and ISPs.
TP-Link SG6428X High-speed Connectivity and Powerful Stacking
- 24× Gigabit RJ45 ports and 4× 10 Gbps SFP+ slots: Expands connectivity with high-speed options, enhancing network performance.
- 128 Gbps switching capacity per unit: Supports high-bandwidth applications with seamless data flow.
- Physical stacking: Allows up to 4 units for built-in redundancy and improved performance, ensuring reliable network operations.
TP-Link SG6428X Abundant Layer 3 Capabilities
- Comprehensive L3 routing protocols: Supports a scalable network with protocols including Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server, and Relay.
- PIM-DM multicast routing: Ensures efficient handling of multicast group communications, optimizing resource usage.
TP-Link SG6428X Highly Available
- Internal redundant power supplies: Guarantees high availability and reliability in network architecture.
- VRRP and ERPS: Provides rapid protection and recovery in ring topologies, minimizing downtime.
TP-Link SG6428X Enhanced Security Functions
- Advanced security measures: Protects against threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, and Port Security.
TP-Link SG6428X Omada SDN
- Centralized cloud management: Integrates with the Omada system for streamlined management and Zero-Touch Provisioning (ZTP), enhancing operational efficiency.
- Intuitive management options: Easily managed via an intuitive web-based GUI, CLI, and supported by SNMP and RMON for network monitoring.
| Feature | Details |
| Ports | 24× Gigabit RJ45, 4× 10 Gbps SFP+ |
| Switching Capacity | 128 Gbps per unit |
| Stacking | Up to 4 units |
| Layer 3 Protocols | Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server/Relay, PIM-DM |
| Security Features | ACL, Port Security, DoS Defend, IEEE 802.1X |
| Power Supply | Internal fixed redundant supplies |
| Management | Omada SDN, web, CLI, SNMP, RMON |
SKU  | SG6428X |
|---|---|
| Manufacturer | TP-Link |
| # of Ports | 24 PORT |
| Data Rate | 10/100/1000 Mbps |
| Management | Managed |
| Form Factor | Rackmount |
| PoE | No |
| Features | ACL, Bandwidth Control, Broadcast Storm, IGMP Snooping, Port Mirroring, QoS, SNMP, VLAN |
There are no related videos.
Write Your Own Review
Manuals & Specifications
SG6428X-Specsheet SG6428X-User-Guide.pdf
