ACTi Y72 5 Megapixel Outdoor Analog Dome Camera with 2.8mm Lens
Model No
Y31
$195.75
Product Highlights
- 5 Megapixel
- Fixed Lens with f2.8mm/F2.0
- Extreme WDR
- Super wide angle
Speak to an expert
The Y72 from ACTi is a high-performance 5 megapixel outdoor analog dome camera equipped with a versatile 2.8mm lens, designed to deliver exceptional clarity and detail for all your surveillance needs. With features such as Extreme WDR and a super wide angle, it ensures that every critical moment is captured vividly, no matter the lighting conditions.
ACTi Y72 Camera Features
- 5 Megapixel: Offers high-resolution imaging for clear and detailed video surveillance, allowing for accurate identification of subjects.
- Fixed Lens with f2.8mm/F2.0: Ideal for capturing wide areas without distortion, making it perfect for outdoor environments.
- Extreme WDR: Processes challenging lighting conditions, balancing bright and dark areas, ensuring optimal visibility in varied environments.
- Super wide angle: Expands coverage area, reducing the number of cameras needed for surveillance and enhancing security.
ACTi Y72 Detailed Camera Specifications
| Feature | Details |
|---|---|
| Model | ACTi Y72 |
| Resolution | 5 Megapixels |
| Lens | 2.8mm Fixed Lens (f2.8mm/F2.0) |
| WDR Technology | Extreme WDR |
| Viewing Angle | Super Wide Angle |
| Application | Outdoor Surveillance |
SKU  | Y72 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Weather Resistant, Wide Dynamic Range |
| Manufacturer | ACTi |
Camera Signal  | Analog, HD-AHD, HD-CVI, HD-TVI |
| Resolution | 5 Megapixel |
| Sensor Option | 1/2.7" CMOS |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Infrared Distance | 61~100 Feet |
| Durability | Weather Resistant |
| Mount Type | Ceiling, Wall |
| Voltage | 12vDC |
| Electronic Shutter | 1/30-1/50000 second (NTSC), 1/25-1/50000 second (PAL) |
| Image Device | 1/2.7" Progressive Scan CMOS |
| IR Distance | 30m/98.42ft |
| Minimum Scene Illumination | Color: 0.02 lux at F2.0 (AGC on); B/W: 0 lux (IR LED on) |
| Operating Humidity | ≤90% RH |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Dimensions (W x H) | (Ø x H): 118mm x 96mm (4.65" x 3.78") |
| Video Output | 1 x BNC connector, supports TVI/AHD/CVI/CVBS |
| Weatherproof | IP67 |
| Digital Noise Reduction | DNR |
| Angle of View | Horizontal: 102.2°, Vertical: 53.9° |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Wide Dynamic Range | Yes |
| Auto Gain Control | Yes |
