Hanwha Vision XNB-A8004 5 Megapixel Network AI Box Camera
SKU
XNB-A8004
Model No
XNB-A8004
$732.25
Product Highlights
- 5MP resolution
- Dual NPU for AI-based Image enhancement
- H.265/H.264: Max. 60fps/50fps(60Hz/50Hz)(WDR off)(2MP) Max.
- 30fps/25fps(60Hz/50Hz)(5MP)
- MJPEG: Max. 30fps(@5MP Max. 5fps)
Speak to an expert
5 Megapixel Network AI Box Camera
- The Hanwha Vision XNB-A8004 is a cutting-edge 5 Megapixel Network AI Box Camera that combines high-resolution imaging with advanced AI capabilities for unparalleled performance. With its dual NPU, this camera enhances image quality through smart algorithms, all while ensuring seamless connectivity and robust video compression formats. Ideal for any surveillance application, it delivers superior clarity and real-time performance to meet modern security needs.
Camera Functions
Audio
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Flickerless
Mirror
Motion Detection
ONVIF
Privacy Masking
WDR
Facial Recognition
Camera Features
| 5MP resolution | Direction, Intrusion) , Slip&Fall detection, Face mask detection, Social distancing detection, Motion detection |
| Dual NPU for AI-based Image enhancement | Business intelligence based on AI engine: People/Vehicle/Crowd counting, Queue management, Heatmap |
| H.265/H.264: Max. 60fps/50fps (60Hz/50Hz) (WDR off) (2MP) Max. | Support BestShot and full attributes |
| 30fps/25fps (60Hz/50Hz) (5MP) | Support Dynamic Privacy Masking |
| MJPEG: Max. 30fps (@5MP Max. 5fps) | extremeWDR, WiseNRâ…¡ (Based on AI engine) , WiseStream (Based on AI engine) |
| Analytics events based on AI engine: Object detection (Person/Face/Vehicle/License plate) , IVA (Virtual line/Area, Enter/Exit, Loitering | Device certificate (Hanwha Vision Root CA) , Secure storage (Secure element with FIPS 140-3 level3/CC EAL6+ certified) , SBOM |
Additional Hanwha Vision Products
SKU  | XNB-A8004 |
|---|---|
| Features | Audio, Auto Gain Control, AI Analytics, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Flickerless, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Wide Dynamic Range, Facial Recognition |
| Manufacturer | Hanwha Vision |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Resolution | 5 Megapixel |
| Mount Type | Bracket Required |
| Compression Method | H.264, M-JPEG, H.265 |
| Voltage | 12vDC, PoE |
| Automatic Gain Control (AGC) | Off, Max gain, Manual |
| Dimensions (W x H) | 81(W)x67(H)x165(D)mm(3.19x2.64x6.48") |
| Electronic Shutter | 2~1/30,000sec |
| Image Device | 1/2.8" CMOS |
| Minimum Scene Illumination | 0.004 |
| Operating Humidity | 0~95% RH(non-condensing) |
| Operating Temperature | -10°C~+55°C(+14°F~+131°F) |
| Power Consumption | Max. 8.9W |
| Digital Noise Reduction | WiseNRâ…¡(Based on AI engine), SSNRâ…¤ |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
