Samsung XNB-8002 6 Megapixel Network Box Camera
SKU
XNB-8002
Model No
XNB-8002
$556.51
Product Highlights
- 6MP resolution
- [email protected] (Color), 0.005Lux(B/W)
- 30fps@6MP (H.265/H.264)
- DIS with built-in Gyro sensor
- WiseStream II support
Speak to an expert
6 Megapixel Network Box Camera
- The Hanwha Vision XNB-8002 is a state-of-the-art 6 megapixel network box camera designed for superior performance and advanced security monitoring. Powered by Wisenet 7 technology, it offers impressive features such as high-resolution video at 30fps, comprehensive video analytics, and enhanced cybersecurity measures, making it an ideal choice for both commercial and residential surveillance needs.
Camera Functions
Audio
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Flickerless
Mirror
Motion Detection
On Screen Display Menu
ONVIF
Privacy Masking
Camera Features
| 6MP resolution | Video Analytics (Defocus detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection |
| [email protected] (Color), 0.005Lux (B/W) | Face/upper body detection, Fog detection, Motion detection, Digital auto tracking, PTZ handover) |
| 30fps@6MP (H.265/H.264) | Dual SD slots (Maximum total capacity 512GB) |
| DIS with built-in Gyro sensor | WiseStream II support |
Additional Hanwha Vision Products
SKU  | XNB-8002 |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Flickerless, Mirror, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking |
| Manufacturer | Hanwha Vision |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 6 Megapixel |
| Lens Type | Not Included |
| Mount Type | Bracket Required |
| Compression Method | H.264, H.265 |
| Durability | Indoor |
| Voltage | 12vDC, 24vAC, PoE |
| Dimensions (W x H) | 81(W)x67(H)x165(D)mm (3.19x2.64x6.48") |
| Electronic Shutter | 1/5~1/12,000sec |
| Image Device | 1/2.8" CMOS |
| Minimum Scene Illumination | Color: 0.05Lux (F1.2, 1/30sec), B/W: 0.005Lux |
| Operating Humidity | Less than 95% RH (non condensing) |
| Operating Temperature | -10°C ~ +55°C(+14°F ~ +131°F) |
| OSD Menu | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Power Consumption | PoE: Maximum 12.95W, typical 8.2W, 12VDC: Maximum 11.5W, typical 7.5W, 24VAC: Maximum 13.5W, typical 8.9W |
| Privacy Zone | 32ea, polygonal zones |
| Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
| Video Output | RJ-45 (10/100/1000BASE-T) |
| Motion Detection Tracking | 8ea, 8point Polygonal zones |
| Automatic White Balance | ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Mirror | Yes |
| ONVIF | Yes |
