Panasonic WV-S8563L 19 Megapixel Network Outdoor Dome Camera with 3.1mm Lens
SKU
WV-S8563L
Model No
WV-S8563L
$2,908.38
Product Highlights
- 3 x 6MP(19MP) 3328x1872 up to 15fps
- 270° coverage with one IP address
- Intelligent Auto (with AI Engine)
- Super Dynamic 120dB
- Color night vision (0.084 to 0.12 lx)
Speak to an expert
The WV-S8563L from Panasonic is a high-performance 19 megapixel network outdoor dome camera equipped with a 3.1mm lens. With its cutting-edge AI Engine, this camera excels in automatic identification of people and vehicles, making surveillance efficient and effective. Designed for effortless installation and featuring a thin, lightweight build, it provides comprehensive 360° and 270° imaging with enhanced night vision capabilities, ensuring clarity around the clock.
Panasonic WV-S8563L Camera Features
- High Resolution: 3 x 6MP(19MP) 3328x1872 up to 15fps for crystal-clear image quality.
- Wide Coverage: 270° coverage with a single IP address for expansive monitoring.
- AI-Powered Analytics: Intelligent Auto function helps in optimizing settings automatically.
- Super Dynamic Range: 120dB technology enables excellent image clarity in challenging lighting conditions.
- Enhanced Night Vision: Color night vision performance (0.084 to 0.12 lx) for monitoring in low light.
- Smart Coding: Efficient data storage with AI Engine reduces bandwidth usage.
- Integrated IR LED: Built-in 360° IR LED ensures visibility in total darkness.
- Continuous View Assistance: Guarantees uninterrupted imaging throughout 360° and 270° fields.
- Adjustable Tilt: Wide range tilt angle adjustment mechanism enhances flexibility in installation.
- ONVIF Compliance: Supports ONVIF® Profile G / M / S / T for seamless integration with other devices.
- Highly Secure: FIPS 140-2 level3 certified for strong data protection.
Detailed Specifications for Panasonic WV-S8563L
| Camera Type | 19 Megapixel Network Outdoor Dome Camera |
| Lens | 3.1mm |
| Resolution | 3328x1872 |
| Frame Rate | Up to 15fps |
| Coverage Angle | 270° with one IP address |
| Dynamic Range | Super Dynamic 120dB |
| Night Vision | Color night vision (0.084 to 0.12 lx) |
| AI Functions | Intelligent Auto, Smart Coding |
| IR LED | Built-in 360° IR LED |
| Adjustment Mechanism | Wide range tilt angle adjustment |
| Compliance | ONVIF® Profile G / M / S / T |
| Security Certification | FIPS 140-2 level3 |
SKU  | WV-S8563L |
|---|---|
| Features | Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, 4K Resolution, Facial Recognition |
| Manufacturer | Panasonic |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 19 Megapixel |
| Lens Type | Fixed |
| Lens Size | 3.1mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, JPEG, H.265 |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | PoE+ |
| Dimensions (W x H) | When using the attachment plate only : ø300 mm × 90 mm (H) {ø11-13/16 inches ×3-17/32 inches (H)} |
| Electronic Shutter | 15 fps mode: Max.1/10000s to Max.16/30s, 12.5 fps mode: Max.1/10000s to Max.16/25s |
| Image Device | 3 x 1/2.8 type CMOS image sensor |
| Minimum Scene Illumination | Color : 0.084 lx {30IRE, F1.44, 1/30 s}, Color : 0.12 lx {50IRE, F1.44, 1/30 s}, BW : 0.05 lx {50IRE, F1.44,1/30 s}, BW: 0 lx {50IRE, F1.44, 1/30 s with IR LED} |
| Operating Humidity | 10 to 100 % (no condensation) |
| Operating Temperature | –40 °C to +60 °C {–40 °F to +140 °F} {Power on range : –20 °C to +60 °C (–4 °F to +140 °F)} Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C(165 °F) |
| OSD Menu | English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Power Consumption | Approx. 15 W |
| Privacy Zone | On / Off (up to 8 zones available) |
| Weatherproof | IP67, IP66 |
| Angle of View | Horizontal : 108°, Vertical : 56° |
| Rotation Angle | 0° (Off)/ 90°/ 180° (Upside-down)/ 270° |
| Motion Detection Tracking | On / Off, 4 areas available |
| IR Distance | 40m/131ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| ONVIF | Yes |
