Weldex WDC-4605XV 1/3” High Resolution Face View Camera, Black Housing
SKU
WDC-4605XV
Model No
WDC-4605XV
$289.00
Product Highlights
- 1/3" Sony Super HAD CCD
- User Friendly OSD Menu Control
- High Resolution of 600 TV Lines
- Easy Camera Level Adjustment
- Day & Night
Speak to an expert
The WDC-4605XV from Weldex is a 1/3” high resolution face view camera, offering exceptional image clarity and versatile functionality, making it the ideal choice for a variety of surveillance applications.
Weldex WDC-4605XV Camera Features
- 1/3" Sony Super HAD CCD: Provides enhanced sensitivity and superior image quality even in low-light conditions.
- User Friendly OSD Menu Control: Simplifies settings adjustments, allowing for quick customization of camera settings.
- High Resolution of 600 TV Lines: Delivers sharp and clear images, ensuring detailed monitoring and security.
- Easy Camera Level Adjustment: Facilitates precise angling of the camera for optimal coverage and efficiency.
- Day & Night Capability: Automatically switches between day and night modes for reliable performance in various lighting conditions.
- Dual Power: DC 12V and AC 24V: Offers flexibility in installation, supporting a wide range of power sources.
- DNR (Digital Noise Reduction): Minimizes video noise to enhance image quality during low light conditions.
- Privacy Function: Safeguards viewer privacy by customizing areas where the camera will not capture footage.
Weldex WDC-4605XV Detailed Camera Specifications
| Image Sensor | 1/3" Sony Super HAD CCD |
| Resolution | 600 TV Lines |
| Power Supply | DC 12V / AC 24V |
| Video Output | Composite Video Output |
| Operating Temperature | -10°C to 50°C |
| Dimensions | Please refer to the product datasheet |
| Weight | Please refer to the product datasheet |
| Special Features | Day & Night, DNR, Privacy Function |
SKU  | WDC-4605XV |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, Privacy Masking |
| Manufacturer | Weldex |
Camera Signal  | Analog |
| Resolution | 600 TVL |
| Sensor Option | 1/3" CCD |
| Lens Type | Fixed |
| Lens Size | 2.9mm |
| Infrared Distance | Non Infrared |
| Durability | Indoor |
| Mount Type | Wall |
| Voltage | 12vDC, 24vAC |
| Electronic Shutter | Auto / manual (1/60 ~ 120,000) |
| Image Device | 1/3”interline transfer CCD |
| Image Pixels Total | 811(H) x 508(V) |
| Image Pixels-Effective | 768(H) x 494(V) |
| Minimum Scene Illumination | 0.3Lux/F1.2(color),0.1Lux/F1.2(B/W), 0.002Lux(sens-up) |
| Operating Humidity | 30% ~ 90%RH |
| Operating Temperature | -10˚C ~ +50˚C |
| OSD Menu | Built-in |
| Privacy Zone | On / off (4 programmable zone) |
| S/N Ratio | 50dB (AGC o ) |
| Scanning Horizontal | NTSC: 15.734KHz, PAL: 15.625KHz |
| Scanning System | 2:1 interlace |
| Scanning Vertical | NTSC: 59.94Hz, PAL: 50.00Hz |
| Signal System | NTSC|PAL |
| Video Output | NTSC: 1.0Vp-p/75 (video 0.714Vp-p SYNC 0.286Vp-p), PAL: 1.0Vp-p/75 (video 0.7Vp-p SYNC 0.3Vp-p) |
| Synchronization | INT/LL selectable, 0-359° (adjustable) |
| Digital Noise Reduction | Off/ low / middle / high (Noise reduction) |
| Mirror | Built-in (Horizontal image inversion) |
| Automatic White Balance | ATW / AWC / manual (1,800˚K ~ 10,500˚K) |
| Auto Gain Control | Off /low /middle/high |
| Motion Detection | On / Off (4 programmable zone) |
| Back Light Compensation | Yes |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Mirror | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Auto Gain Control | Yes |
| Motion Detection Tracking | Yes |
