Weldex WDAC-82NC2HD 2 Megapixel NCUA Analog HD Camera with 3.7mm Lens
SKU
WDAC-82NC2HD
Model No
WDAC-82NC2HD
$297.70
Product Highlights
- 2MP (1920×1080) NCUA covert analog HD camera; 3.7mm fixed pinhole lens; HD analog output (AHD/TVI/CVI/CVBS) for connection to analog HD DVRs; day/night operation; 3D DNR; BLC; auto gain control
- NCUA form factor: the camera housing and pinhole lens configuration is specifically designed to meet the National Credit Union Administration's guidelines for surveillance camera positioning at credit union teller counters and transaction areas, providing face-level covert video capture of members at the transaction window
- Analog HD output: connects to existing analog HD DVR and hybrid DVR infrastructure without requiring an IP network or PoE switch — the correct specification for credit union branches on analog or hybrid DVR systems
- NCUA compliance
Speak to an expert
The Weldex WDAC-82NC2HD is a high-performance 2 Megapixel NCUA Analog HD Camera designed specifically for credit unions. With its discreet 3.7mm lens and NCUA compliance, it ensures superior image capturing while adhering to industry regulations. Offering seamless connectivity to existing analog HD systems, this camera brings enhanced surveillance capabilities to teller counters and transaction areas.
Weldex WDAC-82NC2HD Camera Features
- High Definition Quality: 2MP (1920×1080) resolution provides crystal clear images, ensuring accurate identification of individuals at transaction windows.
- Covert Design: NCUA form factor with a pinhole lens allows for discreet installation, thereby maintaining privacy while enhancing security.
- Seamless Integration: Analog HD output allows connection to existing DVR systems without the need for an IP network, simplifying installation and reducing costs.
- Optimized for Low Light: Features day/night operation with 3D DNR, enhancing image clarity in various lighting conditions.
- User-Friendly Settings: Equipped with BLC and auto gain control for improved image quality in challenging environments.
- Regulatory Compliance: Designed to meet NCUA guidelines, ensuring camera positioning effectively captures face-level video.
Weldex WDAC-82NC2HD Detailed Specifications
| Feature | Details |
|---|---|
| Resolution | 2MP (1920×1080) |
| Lens Type | 3.7mm fixed pinhole lens |
| Output Compatibility | AHD/TVI/CVI/CVBS |
| Day/Night Functionality | Yes |
| 3D DNR | Yes |
| BLC | Yes |
| Auto Gain Control | Yes |
| Form Factor | NCUA compliant for teller counters |
| Installation Requirements | Connects to existing analog HD DVRs |
SKU  | WDAC-82NC2HD |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Wide Dynamic Range |
| Manufacturer | Weldex |
Camera Signal  | Analog, HD-AHD, HD-CVI, HD-TVI |
| Resolution | 2 Megapixel |
| Sensor Option | 1/2.8" CMOS |
| Lens Type | Fixed |
| Lens Size | 3.7mm |
| Mount Type | Ceiling, Wall |
| Voltage | 12vDC |
| Image Device | 1/2.8” 2Megapixel Color SONY STARVIS Sensor |
| Image Pixels-Effective | 1945(H) x 1097(V) |
| Minimum Scene Illumination | Analog HD (NTSC 60Hz : 1080p 30fps) 4-in-1 Video selectable (CVBS/CVI/TVI/AHD) |
| Operating Humidity | 0 ~ 95% RH, non condensing |
| Operating Temperature | -30°C ~ +70°C |
| Dimensions (W x H) | 201.0(W) x 104.0(H) x 59.5(D) |
| Power Consumption | Max 1W |
| S/N Ratio | More than 40dB |
| Angle of View | 114°(D) x 93.2°(H) x 72.5°(V) |
| Automatic White Balance | AWB |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Wide Dynamic Range | Yes |
| Auto Gain Control | Yes |
