Vitek VTD-TND6FPN 6 Megapixel Network Outdoor IR Dome Camera with 1.1mm Lens

SKU
VTD-TND6FPN
Model No
VTD-TND6FPN
$466.67
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • 1/2.9″ 6.0 MegaPixel CMOS Image Sensor
  • Up to 30fps live view @ 6 MegaPixel
  • NDAA Compliant
  • [email protected] Fisheye Lens with 180° Horizontal FOV: 180° (desktop) / 360° (ceiling)
  • 6 High Power Covert IR LEDs with 50' IR Range

The Vitek VTD-TND6FPN is a cutting-edge 6 megapixel outdoor IR dome camera designed for optimal visual coverage and advanced surveillance capabilities. With its NDAA compliance, 180° fisheye lens, and enhanced low-light performance, this camera is perfect for both residential and commercial use. Key features include 2-way audio, remote access via mobile applications, and the ability to dewarp images for detailed analysis, making it an exceptional choice for security monitoring.

Vitek VTD-TND6FPN Camera Features

  • 1/2.9” 6.0 Megapixel CMOS Image Sensor: Ensures high-resolution image capture, providing crystal-clear surveillance footage.
  • Up to 30fps Live View @ 6 Megapixel: Allows for real-time viewing with minimal lag, capturing fast-moving events effortlessly.
  • NDAA Compliant: Meets stringent compliance standards, ensuring reliable and secure video surveillance.
  • [email protected] Fisheye Lens with 180° Horizontal FOV: Provides an expansive field of view, reducing the number of cameras needed for comprehensive coverage.
  • 6 High Power Covert IR LEDs with 50’ IR Range: Facilitates clear night vision, enabling effective monitoring in total darkness.
  • True Mechanical Day/Night Function by ICR: Automatically switches between day and night modes, optimizing image quality.
  • XD-DNR (2D-DNR & 3D-DNR) Noise Reduction: Minimizes noise in low-light conditions, enhancing video clarity.
  • ROI Encoding: Allows for efficient bandwidth management by prioritizing important areas in the scene.
  • H.265/H.264/MJPEG Triple Streaming: Offers versatile streaming options to suit varying network conditions and needs.
  • Secondary Video Output (CVBS): Provides additional connectivity options for flexible integration into existing systems.
  • Remote Viewing via CMS, Edge in IE Mode, and iOS & Android Apps: Enables convenience and accessibility for users to monitor their property from anywhere.
  • ONVIF Compliant: Ensures compatibility with a wide range of security systems and devices.
  • MicroSD Memory Card Slot for Local Recording (up to 256GB): Supports local storage, providing a backup for critical footage.
  • Optional Mounting Accessories: Flexible installation options with junction boxes and mounts for tailored setup.
  • IP67 Ingress Protection + IK10 Impact Resistance Rating: Guarantees durability and performance in challenging outdoor environments.
  • Two Way Audio: Facilitates communication through the camera, enhancing interaction capabilities.
  • 12VDC & PoE Operation: Offers flexible power options for easy installation and connectivity.

Vitek VTD-TND6FPN Detailed Specifications

FeatureDetails
Image Sensor1/2.9” 6.0 Megapixel CMOS
Resolution6 Megapixels
Lens[email protected] Fisheye
Field of View180° Horizontal / 360° Ceiling
IR Range50 feet
NDAA ComplianceYes
Operation ModesDay/Night ICR
Noise ReductionXD-DNR (2D & 3D)
StreamingH.265/H.264/MJPEG
Remote ViewingCMS, Edge, iOS & Android Apps
Ingress ProtectionIP67
Impact ResistanceIK10
AudioTwo-Way Audio
Power Supply12VDC / PoE
MicroSD CapacityUp to 256GB
SKU  VTD-TND6FPN
Features  Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Vandal Resistant, Weather Resistant, Wide Dynamic Range
Manufacturer  Vitek
NDAACompliant
Camera Signal     Network IP
Connection Type  Wired
Infrared Distance    61~100 Feet
Resolution    6 Megapixel
Lens Type    Fixed
Lens Size    1.1mm
Mount Type  Ceiling, Wall
Compression Method    H.264, M-JPEG, H.265
Durability    Vandal Resistant, Weather Resistant
Voltage  12vDC, PoE
Dimensions (W x H)  1.61” × 5.12” (41 × 130mm)
Electronic Shutter    1/25 s ~ 1/100000 s
Image Device    1/2.9” 6.0 MegaPixel CMOS Image Sensor
Operating Humidity    10~90% RH
Operating Temperature    14ºF~122ºF (-10º~50ºC)
Power Consumption  <12W
Protocols  TCP / IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP
Weatherproof    IP67
Digital Noise Reduction    3D & 2D-DNR
IR Distance  30.48m/100ft
AudioYes
Auto Gain Control    Yes
Day/Night    Yes
Digital Noise Reduction    Yes
Back Light Compensation    Yes
Motion Detection Tracking    Yes
Wide Dynamic Range    Yes
ONVIF  Yes
