Vitek VTC-TNT8MEA 8 Megapixel Network IP Outdoor IR Dome Camera with 2.8-12mm Lens
SKU
VTC-TNT8MEA
Model No
VTC-TNT8MEA
$288.00
Product Highlights
- 1/2.8” 8.0 MegaPixel CMOS Image Sensor
- Up to 20fps@8MP (3840 × 2160), Up to 30fps @ 6MP and Lower
- 2.8~12mm Motorized Varifocal Lens
- Dual illumination with Matrix IR (up to 165’ Range) and Knight Guard white light (up to 130’ Range)
- Full-color night vision powered by Knight Guard’s White Light LEDs
Speak to an expert
Transcendent Series NDAA Compliant High Definition 8 Megapixel (4K) IP Network Cameras offer unprecedented performance and value. These simple, easy to install, attractively styled, IP Network Cameras transmit over remote viewing via VMS, Web Browser, and iOS & Android Apps. These models also feature enhanced night vision using White Light emitters.
Features
- 1/2.8” 8.0 MegaPixel CMOS Image Sensor
- Up to 20fps@8MP (3840 × 2160), Up to 30fps @ 6MP and Lower
- 2.8~12mm Motorized Varifocal Lens
- Dual illumination with Matrix IR (up to 165’ Range) and Knight Guard white light (up to 130’ Range)
- Full-color night vision powered by Knight Guard’s White Light LEDs
- True Wide Dynamic Range (120dB)
- True Mechanical Day/Night function by ICR
- XD-DNR (3D & 2D-DNR) Noise Reduction
- Programmable Analytics: Line crossing / Region Intrusion Detection (by human / vehicle classification), Object Abandoned / Missing, Scene Change Detection, Video Blur, Video Color Cast Detection
- H.265+ / H.265 / H.264+ / H.264 / MJPEG
- MicroSD Card Slot for Local Recording (Up to 256GB)
- 1 Ch. Audio In + Built-in Mic*
- Remote Viewing via VMS, Web Browser, and iOS & Android Apps
- ONVIF Compliant
- IP67 Weather Resistance
- 12VDC & PoE (Power over Ethernet) Operation
SKU  | VTC-TNT8MEA |
|---|---|
| Features | Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| Manufacturer | Vitek |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 8 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 2.8-12mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 5.15” × 4.34” (130.7mm × 110.2mm) |
| Electronic Shutter | 1/3s ~ 1/100000s |
| Image Device | 1/2.8” CMOS |
| Minimum Scene Illumination | 0.02 lux @F1.6, AGC On, 0 lux with illumination on |
| Operating Humidity | 95% (non-condensing) |
| Operating Temperature | -22°F~140°F (-30°C~60°C), |
| Power Consumption | ≤9.5W |
| Protocols | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, P2P, QoS |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D & 2D-DNR |
| Angle of View | Horizontal 97.3°~34°, Vertical: 52.3°~17.7°, Diagonal: 116°~37° |
| Rotation Angle | 0°~360° |
| IR Distance | 50m/165ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
There are no related videos.
Write Your Own Review
Manuals & Specifications
VTC-TNT8MEA-Specsheet VTC-TNT8MEA-Quick-Start-Guide
