Vitek VTC-TNT8FEA-2 8 Megapixel Network IP Outdoor IR Dome Camera with 2.8mm Lens
SKU
VTC-TNT8FEA-2
Model No
VTC-TNT8FEA-2
was $248.89 Special Price $248.00
Product Highlights
- 1/2.8” 8.0 MegaPixel (4K) CMOS Image Sensor
- Up to 20fps@8MP (3840 × 2160), Up to 30fps @ 6MP and Lower
- 2.8mm Fixed Iris Lens
- Dual illumination with Matrix IR and Knight Guard white light (up to 100’ Range)
- Full-color night vision powered by Knight Guard’s White Light LEDs
Speak to an expert
The Vitek VTC-TNT8FEA-2 is an advanced 8 Megapixel Network IP Outdoor IR Dome Camera designed for high-performance surveillance in various environments. With cutting-edge technology and robust features, it ensures crystal-clear imaging day and night, while providing flexible installation options and enhanced security measures.
Vitek VTC-TNT8FEA-2 Camera Features
- 8 MegaPixel CMOS Sensor: Captures high-resolution images (3840 × 2160) for exceptional detail and clarity.
- High Frame Rate: Supports up to 20fps@8MP and 30fps@6MP, ensuring smooth video playback for critical surveillance moments.
- 2.8mm Fixed Iris Lens: Offers a wide field of view, perfect for monitoring large areas.
- Dual Illumination: Features Matrix IR and Knight Guard white light for excellent visibility up to 100 feet, even in complete darkness.
- Full-Color Night Vision: Knight Guard’s White Light LEDs provide vivid color images at night, enhancing security capabilities.
Vitek VTC-TNT8FEA-2 Detailed Camera Specifications
| Image Sensor | 1/2.8” 8.0 MegaPixel (4K) CMOS |
| Resolution | Up to 3840 × 2160 (8MP) |
| Frame Rate | Up to 20fps@8MP, 30fps@6MP and Lower |
| Lens Type | 2.8mm Fixed Iris Lens |
| Illumination | Matrix IR and Knight Guard white light |
| Night Vision Range | Up to 100’ |
SKU  | VTC-TNT8FEA-2 |
|---|---|
| Features | Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| Manufacturer | Vitek |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 8 Megapixel |
| Lens Type | Fixed |
| Lens Size | 2.8mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 3.77 × 4.25” (95.7 × 108mm) |
| Electronic Shutter | 1/3s ~ 1/100000s |
| Image Device | 1/2.8” CMOS |
| Minimum Scene Illumination | 0.02 lux @F1.6, AGC ON; 0 lux with illumination on |
| Operating Humidity | 95% (non-condensing) |
| Operating Temperature | -22°F~140°F (-30°C~60°C), |
| Power Consumption | ≤6.5W |
| Protocols | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, 802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, P2P, QoS |
| Weatherproof | IP67 |
| Angle of View | Horizontal FoV: 106°, Vertical FoV: 57°, Diagonal FoV: 124° |
| Rotation Angle | 0°~360° |
| IR Distance | 30m/100ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
