InVid ULT-P2LPR300 2 Megapixel IP Outdoor License Plate Mini Bullet Camera, 8-32mm Lens
- 2 Megapixel (1920x1080) Resolution
- 8-32mm Varifocal Lens
- H.264/H.264+, MJPEG Compression
- True Day/Night
- True WDR 140dB
2 Megapixel IP Outdoor License Plate Mini Bullet Camera
- The InVid ULT-P2LPR300 is a specialized IP Outdoor License Plate Mini Bullet Camera designed for precision and reliability in capturing license plate information. With a high-definition 2 Megapixel resolution (1920 x 1080), this camera delivers sharp and clear images, ensuring accurate and detailed capture of license plates even at high speeds.
The ULT-P2LPR300 features an 8-32mm varifocal lens, providing adjustable focal lengths to focus on different distances with ease. This flexibility allows for optimal positioning to capture license plates in various traffic scenarios and environments. Its True Day/Night functionality ensures excellent performance around the clock, automatically switching between color imaging in daylight and black-and-white imaging in low-light conditions.
Equipped with True Wide Dynamic Range (WDR) technology at 140dB, this camera can handle extreme lighting contrasts, ensuring clear and balanced images even in challenging lighting situations such as glaring headlights or shadows. Built for outdoor use, the ULT-P2LPR300 is designed to withstand harsh weather conditions, providing reliable operation in diverse environments, making it an ideal choice for parking lots, toll booths, and other areas requiring precise license plate recognition.
Camera Functions
Audio
Auto Gain Control
BLC
Day/Night Vision
3D DNR
Motion Detection
Onvif
Weather Resistant
WDR
Camera Features
| 2 Megapixel (1920x1080) Resolution | Free iOS & Android Apps for Smart Phones & Tablets |
| 8-32mm Varifocal Lens | Free Central Management Software (CMS) to manage multiple units & sites from a single platform |
| H.264/H.264+, MJPEG Compression | Free Mac Client |
| True Day/Night | IP67 Weather Resistant |
| True WDR 140dB | 12VDC/PoE Operation |
| 300™ EXIR Range | ONVIF |
| Captures License Plates with Vehicles going up to 100MPH | SD Local Storage, 128GB |
| Audio Input/Output |
What is an LPR Camera?
License Plate Recognition (LPR) Cameras are specialized cameras that will allow you to capture a license plate.
The LPR, combined with the software, allows you to capture, search and save vehicle information. You can save license plates to the software and add categories. For example, if you wanted to keep track of all employee cars, you could add them to a group. If you have a recurring visitor to a company, you could add them to a group.
You can search for license plates by entering the complete number or even just a single letter or number. It will pull up all plates that match the criteria set! Additionally, when you pull the license plate you need, the software will show you the full clip of the vehicle leaving or entering for review.
Setting up the view of the LPR is crucial to accurately capture the plate. It is always a good idea to have additional cameras in the area to capture the entire scene and give you the complete picture.
Additional InVid Products
SKU  | ULT-P2LPR300 |
|---|---|
| Features | Audio, Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Motion Detection Tracking, ONVIF, Weather Resistant, Wide Dynamic Range |
| Manufacturer | InVid |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 2 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 8-32mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, MPEG-4, M-JPEG, H.264+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 100×103.9×311.8mm (3.93”x4.09”x12.28”) |
| Electronic Shutter | 1s ~ 1/100.000s |
| Image Device | 1/2.8” progressive scan CMOS |
| Minimum Scene Illumination | 0.005 Lux @ (F1.4, AGC ON), 0 Lux with IR |
| Operating Humidity | 90% or less (non-condensing) |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Power Consumption | Max. 15W |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D DNR |
| Angle of View | 31.2°~10.2° |
| Back Light Compensation | Yes, zone configurable |
| IR Distance | 91.44m/300ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Motion Detection Tracking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
