Samsung TNO-X6320E2F2T2-C 2 Megapixel Explosion Proof Zoom Camera, 32x Lens
SKU
TNO-X6320E2F2T2-C
Model No
TNO-X6320E2F2T2-C
$10,923.02
Product Highlights
- 2 MP (1920 x 1080) resolution
- 4.44-142.6mm (32x) optical zoom, 16x digital zoom
- H.265, H.264, MJPEG triple codec, WiseStream II
- DIS with built-in Gyro sensor
- Day & Night (ICR), WDR (150dB)
Speak to an expert
2 Megapixel Explosion Proof Zoom Camera, 32x Lens
- The TNO-X6320E2F2-C from Hanwha Vision is a 2 Megapixel Explosion Proof Zoom Camera with a powerful 32x lens, designed for extreme environments. This camera boasts a robust explosion-proof housing, ensuring safety and reliability in hazardous locations. With advanced features like high-resolution imaging, extensive zoom capabilities, and superior video compression, it is ideal for security and surveillance applications where performance and durability are paramount.
Camera Functions
Auto Gain Control
Auto White Balance
BLC
Day/Night Vision
3D DNR
Digital Zoom
Flickerless
Motion Detection
On Screen Display Menu
ONVIF
Privacy Masking
Weather Resistant
WDR
Camera Features
| 2 MP (1920 x 1080) resolution | Video Analytics, dual SDXC memory slots |
| 4.44-142.6mm (32x) optical zoom, 16x digital zoom | Electro-polished 316L stainless steel on all welded assemblies |
| H.265, H.264, MJPEG triple codec, WiseStream II | Camera window in toughened glass |
| DIS with built-in Gyro sensor | Integrated Fiber Optics & Optional Wiper |
| Day & Night (ICR), WDR (150dB) | Supply voltage 110 VAC |
Additional Hanwha Vision Products
SKU  | TNO-X6320E2F2T2-C |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Digital Zoom, Flickerless, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
| Manufacturer | Hanwha Vision |
| NDAA | Compliant |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | Non Infrared |
| Resolution | 2 Megapixel |
| Lens Type | Motorized Zoom |
| Lens Size | 32X |
| Mount Type | Bracket Required, Wall |
| Compression Method | H.264, M-JPEG, H.265 |
| Durability | Weather Resistant |
| Voltage | 110vAC |
| Automatic Gain Control (AGC) | Off / Low / Middle / High |
| Electronic Shutter | Minimum / Maximum / Anti flicker (1 ~ 1 / 12,000sec) |
| Image Device | 1/2.8" 2.4 MP CMOS |
| Image Pixels Total | 1981(H) x 1288(V), 2.55 MP |
| Image Pixels-Effective | 1944(H) x 1212(V), 2.35 MP |
| Minimum Scene Illumination | Color : 0.05 Lux (1/30 sec, F1.6), B/W : 0.005 Lux (1/30 sec, F1.6) |
| Operating Temperature | -60°C ~ +60°C (-76°F ~ +140°F) |
| OSD Menu | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Power Consumption | 37W Maximum |
| Privacy Zone | 24 Zones of rectangle zone |
| Protocols | ONVIF Profile S/G, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| S/N Ratio | 50dB |
| Scanning System | Progressive scan |
| Weatherproof | IP66/67, IP68 (1.5m for 24 hours) |
| Zoom Ratio | Optical 32x |
| Digital Noise Reduction | 2D+3D noise filter |
| Mirror | Off |
| Angle of View | H : 61.8?(Wide) ~ 2.19?(Tele) / V : 36.2?(Wide) ~ 1.24?(Tele) |
| Motion Detection Tracking | 8ea, Polygonal |
| Automatic White Balance | ATW / AWC / Manual / Indoor / Outdoor (Included Mercury & Sodium) |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Automatic White Balance | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
| Digital Zoom | Yes |
