SecurityTronix ST-IP8FTD-BLK 8 Megapixel IR Outdoor Dome Camera with 4mm Lens, Black
SKU
ST-IP8FTD-BLK
Model No
ST-IP8FTD-BLK
$226.54
Product Highlights
- 1/2.5″ Progressive Scan CMOS
- 3840 x 2160@15 fps
- 4mm fixed lens
- Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
- H.265+, H.265, H.264+, H.264
Speak to an expert
The ST-IP8FTD-BLK from SecurityTronix is a high-performance 8-megapixel outdoor IR dome camera with a 4mm lens, designed for exceptional detail and playback capabilities. With features to optimize video transmission and analytics, this camera excels in environments requiring reliable surveillance. Its IP67 weather rating ensures durability, while its advanced imaging technology provides clarity in varying lighting conditions, making it a top choice for security needs.
SecurityTronix ST-IP8FTD-BLK Camera Features
- 1/2.5” Progressive Scan CMOS: Offers superior image quality with high resolution for clear video capture.
- 3840 x 2160@15 fps: Ultra HD 4K recording capability for outstanding detail during live view and playback.
- 4mm fixed lens: Provides optimal viewing angles for accurate surveillance.
- Color sensitivity: 0.01 lux @(F1.2, AGC ON), ensures visibility in low-light conditions and 0 lux with IR for total darkness viewing.
- Compression formats: Supports H.265+, H.265, H.264+, and H.264 for efficient video storage and transmission.
- Advanced behavior analysis: Includes 2 behavior analyses for intelligent video analytics, improving security monitoring.
- 120dB WDR: Wide Dynamic Range technology minimizes lighting issues for clear images in challenging conditions.
- BLC/3D DNR/ROI: Features Backlight Compensation, 3D Noise Reduction, and Region of Interest settings to enhance image quality.
- IP67 weather rating: Ensures reliable performance in various environmental conditions.
- Built-in storage capacity: Supports micro SD/SDHC/SDXC cards up to 128 GB for local video storage.
Detailed Specifications for SecurityTronix ST-IP8FTD-BLK
| Camera Type | 8 Megapixel IR Outdoor Dome Camera |
| Lens Type | 4mm Fixed Lens |
| Image Sensor | 1/2.5” Progressive Scan CMOS |
| Max Resolution | 3840 x 2160 |
| Video Frame Rate | 15 fps |
| Low Light Performance | 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR |
| Video Compression | H.265+, H.265, H.264+, H.264 |
| Weather Proof Rating | IP67 |
| Storage Support | Built-in micro SD/SDHC/SDXC card slot, up to 128 GB |
| Power Options | Power over Ethernet (PoE) or 12V DC power supply |
| Additional Features | Wide Dynamic Range (WDR), BLC, 3D DNR, ROI, Intelligent Video Analytics |
SKU  | ST-IP8FTD-BLK |
|---|---|
| Features | Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, Flickerless, Infrared, Mirror, Motion Detection Tracking, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| Manufacturer | SecurityTronix |
Camera Signal  | Network IP |
| Connection Type | Wired |
| Infrared Distance | 61~100 Feet |
| Resolution | 8 Megapixel |
| Lens Type | Fixed |
| Lens Size | 4mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | Camera: 5"× 3.8" (Φ 127.3 x 95.9 mm), Package: 5.9" x 5.9" x 5.6" (150 x 150 x 141 mm) |
| Electronic Shutter | 1/3 s to 1/100,000 s |
| Image Device | 1/2.5" Progressive Scan CMOS |
| IR Wavelength | 850nm |
| Minimum Scene Illumination | Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR |
| Operating Humidity | 95% or less (non-condensing) |
| Operating Temperature | -22 °F to +140 °F (-30 °C to +60 °C) |
| Power Consumption | 112 VDC, 0.5 A, max. 6.0W PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 7.5 W |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, Q oS, IPv6, Bonjour |
| Video Output | RJ45 |
| Weatherproof | IP67 |
| Digital Noise Reduction | 3D DNR |
| IR Distance | 30m/98ft |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Back Light Compensation | Yes |
| Flickerless | Yes |
| Motion Detection Tracking | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| Mirror | Yes |
| ONVIF | Yes |
