Hanwha Vision SNB-9000 UHD 12 Megapixel 4K Network Camera, No Lens

Name: Hanwha Vision SNB-9000 UHD 12 Megapixel 4K Network Camera, No Lens
Brand: Hanwha Vision
SKU: SNB-9000
Price: 714.35 USD
Availability: InStock

SKU

SNB-9000

Be the first to review this product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Hanwha Vision SNB-9000 UHD 12 Megapixel 4K Network Camera, No Lens SNB-9000 by Hanwha Vision

Model No

SNB-9000

$714.35

Add to Quote

Volume
Discounts

Free System
Design

Lifetime
Tech Support

Free Shipping
Over $450*

Add to Wishlist Add to Compare

Product Highlights

Max. 12M (4000 x 3000) / 8M (3840 x 2160) resolution
20fps@4000 x 3000 / 30fps@3840 x 2160
Simple focus, Day & Night (ICR)
Intelligent video analytics
micro SD/SDHC/SDXC memory slot

Add to Wishlist Add to Compare

Speak to an expert

Call: 800.955.5201 | Request A Call | Live Chat | Message Support

Details

UHD 12 Megapixel 4K Network Camera, No Lens

The SNB-9000 from Hanwha Vision is a 4K UHD 12MP Network Camera (No Lens) designed to deliver exceptional image quality and advanced features for versatile surveillance applications.

Camera Functions

Audio

Auto Gain Control

Auto White Balance

BLC

Day/Night Vision

3D DNR

Mirror

Motion Detection

On Screen Display Menu

Privacy Masking

WDR

4K Resolution

Camera Features


Max. 12M (4000 x 3000) / 8M (3840 x 2160) resolution	H.264, MJPEG dual codec, Multiple streaming
C/CS Mount (Lens Sold Separately)	Bi-directional audio support
Day/Night (ICR)	Motion detection, Tampering, DWDR
Simple focus	Micro SD/SDHC memory slot
Intelligent Video Analytics	8x Digital PTZ
20fps@4000 x 3000 / 30fps@3840 x 2160	12VDC / 24VAC / PoE operation

Specifications

SKU	SNB-9000
Features	Audio, Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, Motion Detection Tracking, On Screen Display Menu, Privacy Masking, Wide Dynamic Range, 4K Resolution
Manufacturer	Hanwha Vision
Camera Signal	Network IP
Connection Type	Wired
Infrared Distance	Non Infrared
Resolution	12 Megapixel
Lens Type	Not Included
Mount Type	Bracket Required
Compression Method	H.264, M-JPEG
Durability	Indoor
Voltage	12vDC, 24vAC, PoE
Automatic Gain Control (AGC)	Off / Low / Middle / High
Dimensions (W x H)	78.3 x 67.3 x 130.4mm (3.08" x 2.65" x 5.13")
Electronic Shutter	Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec)
Image Device	1/2.3" 12M CMOS
Image Pixels Total	12megapixel (4,168 x 3,062)
Image Pixels-Effective	4072(H) x 3046(V)
Minimum Scene Illumination	Color : 0.28Lux (1/30sec, F1.2), 0.01Lux (1sec, F1.2), B/W : 0.03Lux (1/30sec, F1.2), 0.001Lux (1sec, F1.2)
Operating Humidity	Less than 90% RH
Operating Temperature	-10°C ~ +55°C (+14°F ~ +131°F)
OSD Menu	English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,Croatian, Hungarian, Greek, Norwegian, Finnish
Power Consumption	Max. 12.5W (24V AC, 50 ~ 60Hz), Max. 12W (12V DC), Max. 12W (PoE, Class3)
Privacy Zone	Off / On (32 zones of rectangular)
Protocols	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
S/N Ratio	50dB
Scanning System	Progressive
Video Output	CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation BNC type
Digital Noise Reduction	SSNRIII (2D+3D noise filter) (Off / On)
Mirror	Off / On
Motion Detection Tracking	Off / On (4ea 4 points polygonal zones)
Back Light Compensation	Off / BLC / HLC
Automatic White Balance	ATW / AWC / Manual / Indoor / Outdoor / Mecury
Audio	Yes
Auto Gain Control	Yes
Day/Night	Yes
Digital Noise Reduction	Yes
Automatic White Balance	Yes
Back Light Compensation	Yes
Motion Detection Tracking	Yes
On Screen Display Menu	Yes
Privacy Masking	Yes
Wide Dynamic Range	Yes
Mirror	Yes
