EverFocus S200-K4 Camera Kit Includes 1080p Outdoor Full HD MoniVue Cameras (4), 2.7mm Lens, Compatible with EMV400 FHD and EMV400SSD
SKU
S200-K4
Model No
S200-K4
$799.99
Product Highlights
- 1080p Full HD with high flexibility and performance for astounding image
- 1/2.9" Sony 2.12MP CMOS sensor, delivering amazing high sensitivity
- Astounding image quality from the 2.7mm lens
- Special design, easy installation and operation
- D-WDR to improve the visibility under high contrast scene
Speak to an expert
The S200-K4 from EverFocus is a camera kit that Includes 1080p full HD MoniVue cameras (4), IP66 rated 2.7mm mini din cameras, (2) MEC-009 (30ft expansion cable), (1) D-Sub cable, compatible with EMV400 FHD and EMV400SSD.
EverFocus S200-K4 Camera Kit Features
- 1080p Full HD: Experience high flexibility and performance for astounding image clarity.
- 1/2.9" Sony 2.12MP CMOS Sensor: Delivers amazing high sensitivity, ensuring quality images in various lighting conditions.
- 2.7mm Lens: Provides astounding image quality with a wide field of view.
- Easy Installation: Special design for hassle-free setup and operation.
- D-WDR Technology: Improves visibility in high contrast scenes for better image detail.
- Weather Resistance: IP66-rated metal housing protects the cameras from harsh outdoor conditions.
- eZ.Controller Function: Allows users to control camera OSD settings conveniently from the MoniVue Video Recorder.
EverFocus S200-K4 Camera Kit Detailed Specifications
| Feature | Details |
|---|---|
| Camera Resolution | 1080p Full HD |
| Sensor Type | 1/2.9" Sony 2.12MP CMOS |
| Lens Type | 2.7mm |
| MEC-009 Expansion Cable | 30ft (2 included) |
| Cable Type | D-Sub cable (1 included) |
| Weather Resistance Rating | IP66 |
| Compatible With | EMV400 FHD, EMV400SSD |
SKU  | S200-K4 |
|---|---|
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Mirror, On Screen Display Menu, Weather Resistant, Wide Dynamic Range |
| Manufacturer | EverFocus |
Camera Signal  | HD-AHD |
| Resolution | 1080p |
| Sensor Option | 1/2.9" CMOS |
| Lens Type | Fixed |
| Lens Size | 2.7mm |
| Infrared Distance | Non Infrared |
| Durability | Weather Resistant |
| Mount Type | Bracket Required |
| Voltage | 12vDC |
| Electronic Shutter | Auto / Manual (1 ~ 1/50,000) / FLK |
| Gamma Correction | 0.45 |
| Image Device | 1/2.9" Sony 2.24MP CMOS |
| Image Pixels-Effective | 1920 (H) x 1080 (V) |
| Minimum Scene Illumination | 0.2Lux |
| Operating Humidity | Less than 90% |
| Operating Temperature | -20°C ~ 50°C / -4°F ~ 122°F |
| Dimensions (W x H) | 32.3 x 25mm / 1.27" x 0.99" |
| OSD Menu | English / Simplified Chinese / Traditional Chinese / German / French / Italian / Spanish / Polish / Russian / Portuguese / Netherlands / Turkish / Japanese |
| Power Consumption | 12VDC, 0.1A max. |
| S/N Ratio | > 45dB |
| Scanning System | Progressive Scan |
| Signal System | NTSC / PAL |
| Video Output | Mini DIN 1.0Vp-p 75Ω |
| Weatherproof | IP66 |
| Synchronization | Internal |
| Digital Noise Reduction | 2DNR |
| Mirror | Off / Mirror / V-Flip / Rotate |
| Automatic White Balance | ATW / AWC-SET / Indoor / Outdoor / Manual |
| Auto Gain Control | 0 ~ 15 Levels |
| Back Light Compensation | Yes |
| Automatic White Balance | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| Mirror | Yes |
| On Screen Display Menu | Yes |
| Wide Dynamic Range | Yes |
| Auto Gain Control | Yes |
