RVS Systems RVS-775L-03 120° 420 TVL Black Left Side Camera, 16' Cable, 2.1mm Lens

SKU
RVS-775L-03
Model No
RVS-775L-03
$257.41
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • 120° angle left side camera, Black
  • Weather-resistant
  • 16' Cable
  • 2.1mm Lens

The RVS-775L-03 from RVS Systems is a 120° angle left side camera which is the clearest and greatest camera available on the market today. It boasts a 250,000 pixel 2.1 mm lens with 9 infra-red illuminators which enable you to see in total darkness. The casing of the camera has an IP68 rating which can withstand all weather conditions. This camera comes with 16' camera cable with a double-sided Female Air-Craft Grade Connection. This cable runs the length of the vehicle, from the camera to the multiplexer or power harness.

RVS Systems RVS-775L-03 Camera Features

  • 120° Angle: Provides a wide field of view for enhanced visibility, making it ideal for monitoring blind spots.
  • High Resolution: 250,000 pixels ensure clear and detailed images for better safety and surveillance.
  • Infra-red Illuminators: Equipped with 9 infra-red lights for night vision, allowing you to see in total darkness.
  • Weather-resistant (IP68 Rating): Built to withstand harsh weather conditions, ensuring longevity and durability.
  • 16' Cable: Comes with a long cable that enables flexible installation across various vehicle sizes.
  • 2.1mm Lens: Optimized lens for superior clarity and performance, enhancing your viewing experience.

RVS Systems RVS-775L-03 Detailed Camera Specifications

Camera TypeLeft Side Camera
Field of View120°
Resolution250,000 Pixels
Lens Diameter2.1mm
Infra-red Lights9
Weather ResistanceIP68
Cable Length16'
ConnectorsDouble-sided Female Air-Craft Grade Connection
SKU  RVS-775L-03
Features  Auto Gain Control, Weather Resistant
Manufacturer  RVS Systems
Camera Signal     Analog
Resolution    420 TVL
Sensor Option    1/4" CCD
Lens Type    Fixed
Lens Size    2.1mm
Infrared Distance    0~60 Feet
Durability    Weather Resistant
Voltage  12-24vDC
Gamma Correction  R=0.45 to 1.0
Image Device    1/4" Sharp Color CCD
IR Distance  9.14m/30ft
Minimum Scene Illumination  0 Lux (IR On)
Operating Humidity    RH 95% Max
Operating Temperature    -40°C ~ +80°C
S/N Ratio  More than 48dB
Video Output    1Vp.p 75 Ω
Weatherproof    IP68
Synchronization  Internal Synchronization
Angle of View    120°
IR LEDs  9
Auto Gain Control    Yes
