RVS Systems RVS-770615 620 TVL Analog Outdoor Backup Camera System with Three Camera Setup, 2.5mm Lens

SKU
RVS-770615
Model No
RVS-082509
$399.60
Volume Discounts Volume
Discounts
Free System Design Free System
Design
Lifetime Tech Support Lifetime
Tech Support
Free Shipping Over $450* Free Shipping
Over $450*
Product Highlights
  • Backup Camera System with Three Cameras
  • 7" or 9" LED Digital Panel Color Display
  • 130° Ultra Wide Viewing Angle
  • Waterproof Backup Cameras with Infra-Red Night Vision
  • Optional Quad View Upgrade

The RVS Systems RVS-770615 620 TVL Analog Outdoor Backup Camera System is an advanced solution for enhanced safety and visibility while reversing. This system includes three high-quality cameras and a state-of-the-art 7" LED Digital Panel monitor, designed to provide crystal clear images, ensuring you can easily navigate tight spaces and avoid obstacles. With features like high-resolution night vision and a robust, weatherproof design, this camera system is perfect for outdoor use.

RVS Systems RVS-770615 Camera Features

  • Three Camera Setup: Provides comprehensive coverage with three cameras featuring a 130° ultra-wide viewing angle, enhancing safety while reversing and maneuvering.
  • 7" LED Digital Panel: The easy-to-read color display includes distance grid lines and mirror image capability, allowing for accurate distance judgment.
  • Infra-Red Night Vision: Ensures visibility in low-light conditions, making it ideal for nighttime use.
  • Weatherproof Design: With an IP69K rating, the cameras are fully weatherproof, protecting against extreme conditions.
  • Shock and Vibration Resistant: Rated for up to 20G vibration resistance, the cameras are built to last in challenging environments.

Detailed Specifications for RVS Systems RVS-770615

ModelRVS-770615
Camera Resolution620 TVL
Total CamerasThree (3)
Viewing Angle130°
Display Size7 inches
Infra-Red Night VisionYes, with 50ft range
Weatherproof RatingIP69K
Vibration Rating20G
Included AccessoriesWires, connectors, and mounts
Optional FeaturesQuad View Upgrade
SKU  RVS-770615
Features  Auto Gain Control, Day/Night, Weather Resistant
Manufacturer  RVS Systems
Camera Signal     Analog
Resolution    620 TVL
Sensor Option    1/3" CCD
Lens Type    Fixed
Lens Size    2.5mm
Infrared Distance    0~60 Feet
Durability    Weather Resistant
Mount Type  Ceiling, Wall
Electronic Shutter    1/50, 160-1/100,000sec
Gamma Correction  r=0.45 to 1.0
Image Device    1/3" Sharp® Color CCD
IR Distance  15.24m/50ft
Minimum Scene Illumination  0 Lux (IR On)
Operating Humidity    RH 95% Max
Operating Temperature    -40°C ~ +70°C
Dimensions (W x H)  Camera: (with bracket) 3.25" (H) x 3" (L) x 1.5" (D), Monitor: 5.25" (H) x 7" (L) x 1" (D)
Power Consumption  5W CVBS
S/N Ratio  More than 48dB
Signal System    PAL/NTSC
Video Output    1Vp-p, 75Ω
Weatherproof    IP69
Synchronization  Internal
Angle of View    130°
IR LEDs  18
AudioYes
Day/Night    Yes
Auto Gain Control    Yes
